Ultimate POS Watermark Feature - Complete Implementation Guide

This guide walks you through adding a watermark feature to your Ultimate POS invoice templates, allowing users to add custom logos as watermarks on their invoices.

Overview

The watermark feature allows users to:

• Upload a custom watermark logo
• Control watermark visibility (show/hide)
• Adjust watermark size (width/height)
• Set transparency level (opacity)
• Choose watermark position (center, corners)

Prerequisites

• Ultimate POS system installed and running
• Access to database and codebase
• Basic knowledge of Laravel, PHP, and Blade templates

Step 1: Database Migration

Create Migration File

Create a new migration to add watermark fields to the invoice_layouts table:

php artisan make:migration add_watermark_fields_to_invoice_layouts --table=invoice_layouts

Migration Code

Replace the generated migration content with:

<?php

use Illuminate\Database\Migrations\Migration;
use Illuminate\Database\Schema\Blueprint;
use Illuminate\Support\Facades\Schema;

return new class extends Migration
{
    /**
     * Run the migrations.
     *
     * @return void
     */
    public function up()
    {
        Schema::table('invoice_layouts', function (Blueprint $table) {
            $table->string('watermark_logo')->nullable()->after('logo');
            $table->boolean('show_watermark')->default(0)->after('watermark_logo');
            $table->integer('watermark_width')->default(300)->after('show_watermark');
            $table->integer('watermark_height')->default(300)->after('watermark_width');
            $table->decimal('watermark_opacity', 3, 2)->default(0.10)->after('watermark_height');
            $table->string('watermark_position')->default('center')->after('watermark_opacity');
        });
    }

    /**
     * Reverse the migrations.
     *
     * @return void
     */
    public function down()
    {
        Schema::table('invoice_layouts', function (Blueprint $table) {
            $table->dropColumn([
                'watermark_logo',
                'show_watermark',
                'watermark_width',
                'watermark_height',
                'watermark_opacity',
                'watermark_position'
            ]);
        });
    }
};

Run Migration

Execute the migration:

php artisan migrate

Or run specific migration:

php artisan migrate --path=database/migrations/2025_07_29_125312_add_watermark_fields_to_invoice_layouts.php

Alternative: Direct SQL Execution

If you prefer to run SQL directly or need to add columns to an existing system, you can execute these SQL commands:

ALTER TABLE `invoice_layouts`
ADD COLUMN `watermark_logo` VARCHAR(255) NULL AFTER `logo`,
ADD COLUMN `show_watermark` TINYINT(1) NOT NULL DEFAULT 0 AFTER `watermark_logo`,
ADD COLUMN `watermark_width` INT NOT NULL DEFAULT 300 AFTER `show_watermark`,
ADD COLUMN `watermark_height` INT NOT NULL DEFAULT 300 AFTER `watermark_width`,
ADD COLUMN `watermark_opacity` DECIMAL(3,2) NOT NULL DEFAULT 0.10 AFTER `watermark_height`,
ADD COLUMN `watermark_position` VARCHAR(50) NOT NULL DEFAULT 'center' AFTER `watermark_opacity`;

Rollback SQL (if needed)

To remove the watermark columns:

ALTER TABLE `invoice_layouts`
DROP COLUMN `watermark_logo`,
DROP COLUMN `show_watermark`,
DROP COLUMN `watermark_width`,
DROP COLUMN `watermark_height`,
DROP COLUMN `watermark_opacity`,
DROP COLUMN `watermark_position`;

Step 2: Update Model

Update InvoiceLayout Model

Add watermark field casting to app/InvoiceLayout.php:

<?php

namespace App;

use Illuminate\Database\Eloquent\Model;

class InvoiceLayout extends Model
{
    /**
     * The attributes that aren't mass assignable.
     *
     * @var array
     */
    protected $guarded = ['id'];

    /**
     * The attributes that should be cast to native types.
     *
     * @var array
     */
    protected $casts = [
        'product_custom_fields' => 'array',
        'contact_custom_fields' => 'array',
        'location_custom_fields' => 'array',
        'common_settings' => 'array',
        'qr_code_fields' => 'array',
        // Add watermark casts
        'show_watermark' => 'boolean',
        'watermark_width' => 'integer',
        'watermark_height' => 'integer',
        'watermark_opacity' => 'decimal:2',
    ];

    /**
     * Get the location associated with the invoice layout.
     */
    public function locations()
    {
        return $this->hasMany(\App\BusinessLocation::class);
    }

    /**
     * Return list of invoice layouts for a business
     *
     * @param  int  $business_id
     * @return array
     */
    public static function forDropdown($business_id)
    {
        $layouts = InvoiceLayout::where('business_id', $business_id)
            ->pluck('name', 'id');

        return $layouts;
    }
}

Step 3: Update Controller

Update Store Method

Modify the store method in InvoiceLayoutController.php:

    /**
     * Store a newly created resource in storage.
     *
     * @param  \Illuminate\Http\Request  $request
     * @return \Illuminate\Http\Response
     */
    public function store(Request $request)
    {
        if (! auth()->user()->can('invoice_settings.access')) {
            abort(403, 'Unauthorized action.');
        }

        try {
            $validator = Validator::make($request->all(), [
                'logo' => 'mimes:jpeg,gif,png|max:1000',
                'watermark_logo' => 'mimes:jpeg,gif,png|max:1000', // Add watermark validation
            ]);

            $input = $request->only([
                'name',
                'header_text',
                'invoice_no_prefix',
                'invoice_heading',
                'sub_total_label',
                'discount_label',
                'tax_label',
                'total_label',
                'highlight_color',
                'footer_text',
                'invoice_heading_not_paid',
                'invoice_heading_paid',
                'total_due_label',
                'customer_label',
                'paid_label',
                'sub_heading_line1',
                'sub_heading_line2',
                'sub_heading_line3',
                'sub_heading_line4',
                'sub_heading_line5',
                'table_product_label',
                'table_qty_label',
                'table_unit_price_label',
                'table_subtotal_label',
                'client_id_label',
                'date_label',
                'quotation_heading',
                'quotation_no_prefix',
                'design',
                'client_tax_label',
                'cat_code_label',
                'cn_heading',
                'cn_no_label',
                'cn_amount_label',
                'sales_person_label',
                'prev_bal_label',
                'date_time_format',
                'common_settings',
                'change_return_label',
                'round_off_label',
                'qr_code_fields',
                'commission_agent_label',
                // Add watermark fields
                'watermark_width',
                'watermark_height',
                'watermark_opacity',
                'watermark_position'
            ]);

            $business_id = $request->session()->get('user.business_id');
            $input['business_id'] = $business_id;

            //Set value for checkboxes
            $checkboxes = [
                'show_business_name',
                'show_location_name',
                'show_landmark',
                'show_city',
                'show_state',
                'show_country',
                'show_zip_code',
                'show_mobile_number',
                'show_alternate_number',
                'show_email',
                'show_tax_1',
                'show_tax_2',
                'show_logo',
                'show_barcode',
                'show_payments',
                'show_customer',
                'show_client_id',
                'show_brand',
                'show_sku',
                'show_cat_code',
                'show_sale_description',
                'show_sales_person',
                'show_expiry',
                'show_lot',
                'show_previous_bal',
                'show_image',
                'show_reward_point',
                'show_qr_code',
                'show_commission_agent',
                'show_letter_head',
                'show_watermark' // Add watermark checkbox
            ];
            foreach ($checkboxes as $name) {
                $input[$name] = ! empty($request->input($name)) ? 1 : 0;
            }

            //Upload Logo
            $logo_name = $this->commonUtil->uploadFile($request, 'logo', 'invoice_logos', 'image');
            if (! empty($logo_name)) {
                $input['logo'] = $logo_name;
            }

            $letter_head = $this->commonUtil->uploadFile($request, 'letter_head', 'invoice_logos', 'image');
            if (! empty($letter_head)) {
                $input['letter_head'] = $letter_head;
            }

            // Upload Watermark Logo
            $watermark_logo_name = $this->commonUtil->uploadFile($request, 'watermark_logo', 'invoice_logos', 'image');
            if (! empty($watermark_logo_name)) {
                $input['watermark_logo'] = $watermark_logo_name;
            }

            // Set default values for watermark settings
            $input['watermark_width'] = $request->input('watermark_width', 300);
            $input['watermark_height'] = $request->input('watermark_height', 300);
            $input['watermark_opacity'] = $request->input('watermark_opacity', '0.1');
            $input['watermark_position'] = $request->input('watermark_position', 'center');

            if (! empty($request->input('is_default'))) {
                //get_default
                $default = InvoiceLayout::where('business_id', $business_id)
                    ->where('is_default', 1)
                    ->update(['is_default' => 0]);
                $input['is_default'] = 1;
            }

            //Module info
            if ($request->has('module_info')) {
                $input['module_info'] = json_encode($request->input('module_info'));
            }

            if (! empty($request->input('table_tax_headings'))) {
                $input['table_tax_headings'] = json_encode($request->input('table_tax_headings'));
            }
            $input['product_custom_fields'] = ! empty($request->input('product_custom_fields')) ? $request->input('product_custom_fields') : null;
            $input['contact_custom_fields'] = ! empty($request->input('contact_custom_fields')) ? $request->input('contact_custom_fields') : null;
            $input['location_custom_fields'] = ! empty($request->input('location_custom_fields')) ? $request->input('location_custom_fields') : null;

            InvoiceLayout::create($input);
            $output = [
                'success' => 1,
                'msg' => __('invoice.layout_added_success'),
            ];
        } catch (\Exception $e) {
            \Log::emergency('File:' . $e->getFile() . 'Line:' . $e->getLine() . 'Message:' . $e->getMessage());

            $output = [
                'success' => 0,
                'msg' => __('messages.something_went_wrong'),
            ];
        }

        return redirect('invoice-schemes')->with('status', $output);
    }

Update Update Method

Modify the update method in InvoiceLayoutController.php:

   /**
     * Update the specified resource in storage.
     *
     * @param  \Illuminate\Http\Request  $request
     * @param  \App\InvoiceLayout  $invoiceLayout
     * @return \Illuminate\Http\Response
     */
    public function update(Request $request, $id)
    {
        if (! auth()->user()->can('invoice_settings.access')) {
            abort(403, 'Unauthorized action.');
        }

        try {
            $validator = Validator::make($request->all(), [
                'logo' => 'mimes:jpeg,gif,png|1000',
                'watermark_logo' => 'mimes:jpeg,gif,png|1000', // Add watermark validation
            ]);

            $input = $request->only([
                'name',
                'header_text',
                'invoice_no_prefix',
                'invoice_heading',
                'sub_total_label',
                'discount_label',
                'tax_label',
                'total_label',
                'highlight_color',
                'footer_text',
                'invoice_heading_not_paid',
                'invoice_heading_paid',
                'total_due_label',
                'customer_label',
                'paid_label',
                'sub_heading_line1',
                'sub_heading_line2',
                'sub_heading_line3',
                'sub_heading_line4',
                'sub_heading_line5',
                'table_product_label',
                'table_qty_label',
                'table_unit_price_label',
                'table_subtotal_label',
                'client_id_label',
                'date_label',
                'quotation_heading',
                'quotation_no_prefix',
                'design',
                'client_tax_label',
                'cat_code_label',
                'cn_heading',
                'cn_no_label',
                'cn_amount_label',
                'sales_person_label',
                'prev_bal_label',
                'date_time_format',
                'change_return_label',
                'round_off_label',
                'commission_agent_label',
                // Add watermark fields
                'watermark_width',
                'watermark_height',
                'watermark_opacity',
                'watermark_position'
            ]);
            $business_id = $request->session()->get('user.business_id');

            $checkboxes = [
                'show_business_name',
                'show_location_name',
                'show_landmark',
                'show_city',
                'show_state',
                'show_country',
                'show_zip_code',
                'show_mobile_number',
                'show_alternate_number',
                'show_email',
                'show_tax_1',
                'show_tax_2',
                'show_logo',
                'show_barcode',
                'show_payments',
                'show_customer',
                'show_client_id',
                'show_brand',
                'show_sku',
                'show_cat_code',
                'show_sale_description',
                'show_sales_person',
                'show_expiry',
                'show_lot',
                'show_previous_bal',
                'show_image',
                'show_reward_point',
                'show_qr_code',
                'show_commission_agent',
                'show_letter_head',
                'show_watermark', // Add watermark checkbox
            ];
            foreach ($checkboxes as $name) {
                $input[$name] = ! empty($request->input($name)) ? 1 : 0;
            }

            //Upload Logo
            $logo_name = $this->commonUtil->uploadFile($request, 'logo', 'invoice_logos', 'image');
            if (! empty($logo_name)) {
                $input['logo'] = $logo_name;
            }

            //Upload letter head
            $letter_head = $this->commonUtil->uploadFile($request, 'letter_head', 'invoice_logos', 'image');
            if (! empty($letter_head)) {
                $input['letter_head'] = $letter_head;
            }

            //Upload Watermark Logo
            $watermark_logo_name = $this->commonUtil->uploadFile($request, 'watermark_logo', 'invoice_logos', 'image');
            if (! empty($watermark_logo_name)) {
                $input['watermark_logo'] = $watermark_logo_name;
            }

            // Set default values for watermark settings
            $input['watermark_width'] = $request->input('watermark_width', 300);
            $input['watermark_height'] = $request->input('watermark_height', 300);
            $input['watermark_opacity'] = $request->input('watermark_opacity', '0.1');
            $input['watermark_position'] = $request->input('watermark_position', 'center');

            if (! empty($request->input('is_default'))) {
                //get_default
                $default = InvoiceLayout::where('business_id', $business_id)
                    ->where('is_default', 1)
                    ->update(['is_default' => 0]);
                $input['is_default'] = 1;
            }

            //Module info
            if ($request->has('module_info')) {
                $input['module_info'] = json_encode($request->input('module_info'));
            }

            if (! empty($request->input('table_tax_headings'))) {
                $input['table_tax_headings'] = json_encode($request->input('table_tax_headings'));
            }

            $input['product_custom_fields'] = ! empty($request->input('product_custom_fields')) ? json_encode($request->input('product_custom_fields')) : null;
            $input['contact_custom_fields'] = ! empty($request->input('contact_custom_fields')) ? json_encode($request->input('contact_custom_fields')) : null;
            $input['location_custom_fields'] = ! empty($request->input('location_custom_fields')) ? json_encode($request->input('location_custom_fields')) : null;
            $input['common_settings'] = ! empty($request->input('common_settings')) ? json_encode($request->input('common_settings')) : null;
            $input['qr_code_fields'] = ! empty($request->input('qr_code_fields')) ? json_encode($request->input('qr_code_fields')) : null;

            InvoiceLayout::where('id', $id)
                ->where('business_id', $business_id)
                ->update($input);
            $output = [
                'success' => 1,
                'msg' => __('invoice.layout_updated_success'),
            ];
        } catch (\Exception $e) {
            \Log::emergency('File:' . $e->getFile() . 'Line:' . $e->getLine() . 'Message:' . $e->getMessage());

            $output = [
                'success' => 0,
                'msg' => __('messages.something_went_wrong'),
            ];
        }

        return redirect('invoice-schemes')->with('status', $output);
    }

Step 4: Add Language Strings

Update Language File

Add watermark-related language strings to resources/lang/en/lang_v1.php:

    'watermark_settings' => 'Watermark Settings',
    'watermark_logo' => 'Watermark Logo',
    'watermark_logo_help' => 'Logo image for watermark. Max file size: :max_size',
    'show_watermark' => 'Show Watermark',
    'watermark_width' => 'Watermark Width',
    'watermark_height' => 'Watermark Height',
    'watermark_opacity' => 'Watermark Opacity',
    'watermark_position' => 'Watermark Position',
    'width_in_pixels' => 'Width in pixels (50-800)',
    'height_in_pixels' => 'Height in pixels (50-800)',
    'transparency_level' => 'Transparency level',
    'center' => 'Center',
    'top_left' => 'Top Left',
    'top_right' => 'Top Right',
    'bottom_left' => 'Bottom Left',
    'bottom_right' => 'Bottom Right',
    'current_watermark' => 'Current watermark logo',

Step 5: Update Forms

Add Watermark Section to Create Form

In your invoice layout create form (typically resources/views/invoice_layout/create.blade.php), add the watermark settings section:

@extends('layouts.app')
@section('title', __('invoice.add_invoice_layout'))

@section('content')
<style type="text/css">



</style>
@php
$custom_labels = json_decode(session('business.custom_labels'), true);
@endphp
<!-- Content Header (Page header) -->
<section class="content-header">
  <h1 class="tw-text-xl md:tw-text-3xl tw-font-bold tw-text-black">@lang('invoice.add_invoice_layout')</h1>
</section>

<!-- Main content -->
<section class="content">
  {!! Form::open(['url' => action([\App\Http\Controllers\InvoiceLayoutController::class, 'store']), 'method' => 'post',
  'id' => 'add_invoice_layout_form', 'files' => true]) !!}
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('name', __('invoice.layout_name') . ':*') !!}
            {!! Form::text('name', null, ['class' => 'form-control', 'required',
            'placeholder' => __('invoice.layout_name')]); !!}
          </div>
        </div>
        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('design', __('lang_v1.design') . ':*') !!}
            {!! Form::select('design', $designs, 'classic', ['class' => 'form-control']); !!}
            <span class="help-block">
              @lang('lang_v1.used_for_browser_based_printing')
            </span>
          </div>

          <div class="form-group hide" id="columnize-taxes">
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" required="required"
                placeholder="tax 1 name" disabled>
              @show_tooltip(__('lang_v1.tooltip_columnize_taxes_heading'))
            </div>
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" placeholder="tax 2 name" disabled>
            </div>
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" placeholder="tax 3 name" disabled>
            </div>
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" placeholder="tax 4 name" disabled>
            </div>
          </div>

        </div>
        <div class="clearfix"></div>
        <div class="col-sm-6">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_letter_head', 1, false,
                ['class' => 'input-icheck', 'id' => 'show_letter_head']); !!} @lang('lang_v1.show_letter_head')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-6 letter_head_input hide">
          <div class="form-group">
            {!! Form::label('letter_head', __('lang_v1.letter_head') . ':') !!}
            {!! Form::file('letter_head', ['accept' => 'image/*']); !!}
            <span class="help-block">@lang('lang_v1.letter_head_help') <br> @lang('lang_v1.invoice_logo_help',
              ['max_size' => '1 MB'])</span>
          </div>
        </div>
        <div class="clearfix"></div>

        <!-- Logo -->
        <div class="col-sm-6 hide-for-letterhead">
          <div class="form-group">
            {!! Form::label('logo', __('invoice.invoice_logo') . ':') !!}
            {!! Form::file('logo', ['accept' => 'image/*']); !!}
            <span class="help-block">@lang('lang_v1.invoice_logo_help', ['max_size' => '1 MB'])</span>
          </div>
        </div>
        <div class="col-sm-6 hide-for-letterhead">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_logo', 1, false, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_logo')</label>
            </div>
          </div>
        </div>






        <div class="col-sm-12 hide-for-letterhead">
          <div class="form-group">
            {!! Form::label('header_text', __('invoice.header_text') . ':' ) !!}
            {!! Form::textarea('header_text','', ['class' => 'form-control',
            'placeholder' => __('invoice.header_text'), 'rows' => 3]); !!}
          </div>
        </div>
      </div>
      <div class="row hide-for-letterhead">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line1', __('lang_v1.sub_heading_line', ['_number_' => 1]) . ':' ) !!}
            {!! Form::text('sub_heading_line1', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 1]) ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line2', __('lang_v1.sub_heading_line', ['_number_' => 2]) . ':' ) !!}
            {!! Form::text('sub_heading_line2', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 2]) ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line3', __('lang_v1.sub_heading_line', ['_number_' => 3]) . ':' ) !!}
            {!! Form::text('sub_heading_line3', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 3]) ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line4', __('lang_v1.sub_heading_line', ['_number_' => 4]) . ':' ) !!}
            {!! Form::text('sub_heading_line4', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 4]) ]); !!}
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line5', __('lang_v1.sub_heading_line', ['_number_' => 5]) . ':' ) !!}
            {!! Form::text('sub_heading_line5', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 5]) ]); !!}
          </div>
        </div>
      </div>
    </div>
  </div>




  <div class="box box-solid">
    <div class="box-body">
      <div class="row">

        <!-- Watermark Settings Section -->
        <div class="col-sm-12">
          <h4>@lang('lang_v1.watermark_settings'):</h4>
        </div>

        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('watermark_logo', __('lang_v1.watermark_logo') . ':') !!}
            {!! Form::file('watermark_logo', ['accept' => 'image/*']); !!}
            <span class="help-block">@lang('lang_v1.watermark_logo_help', ['max_size' => '1 MB'])</span>
          </div>
        </div>

        <div class="col-sm-6">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_watermark', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_watermark')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_width', __('lang_v1.watermark_width') . ':') !!}
            {!! Form::number('watermark_width', 300, ['class' => 'form-control', 'min' => '50', 'max' => '800',
            'placeholder' => '300']); !!}
            <span class="help-block">@lang('lang_v1.width_in_pixels')</span>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_height', __('lang_v1.watermark_height') . ':') !!}
            {!! Form::number('watermark_height', 300, ['class' => 'form-control', 'min' => '50', 'max' => '800',
            'placeholder' => '300']); !!}
            <span class="help-block">@lang('lang_v1.height_in_pixels')</span>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_opacity', __('lang_v1.watermark_opacity') . ':') !!}
            {!! Form::select('watermark_opacity', [
            '0.05' => '5%',
            '0.1' => '10%',
            '0.15' => '15%',
            '0.2' => '20%',
            '0.25' => '25%',
            '0.3' => '30%'
            ], '0.1', ['class' => 'form-control']); !!}
            <span class="help-block">@lang('lang_v1.transparency_level')</span>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_position', __('lang_v1.watermark_position') . ':') !!}
            {!! Form::select('watermark_position', [
            'center' => __('lang_v1.center'),
            'top-left' => __('lang_v1.top_left'),
            'top-right' => __('lang_v1.top_right'),
            'bottom-left' => __('lang_v1.bottom_left'),
            'bottom-right' => __('lang_v1.bottom_right')
            ], 'center', ['class' => 'form-control']); !!}
          </div>
        </div>
      </div>
    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_heading', __('invoice.invoice_heading') . ':' ) !!}
            {!! Form::text('invoice_heading', 'Invoice', ['class' => 'form-control',
            'placeholder' => __('invoice.invoice_heading') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_heading_not_paid', __('invoice.invoice_heading_not_paid') . ':' ) !!}
            {!! Form::text('invoice_heading_not_paid', null, ['class' => 'form-control',
            'placeholder' => __('invoice.invoice_heading_not_paid') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_heading_paid', __('invoice.invoice_heading_paid') . ':' ) !!}
            {!! Form::text('invoice_heading_paid', null, ['class' => 'form-control',
            'placeholder' => __('invoice.invoice_heading_paid') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('proforma_heading', __('lang_v1.proforma_heading') . ':' ) !!}
            @show_tooltip(__('lang_v1.tooltip_proforma_heading'))
            {!! Form::text('common_settings[proforma_heading]', __('lang_v1.proforma_invoice'), ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.proforma_heading'), 'id' => 'proforma_heading' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('quotation_heading', __('lang_v1.quotation_heading') . ':' ) !!}
            @show_tooltip(__('lang_v1.tooltip_quotation_heading'))
            {!! Form::text('quotation_heading', __('lang_v1.quotation'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.quotation_heading') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sales_order_heading', __('lang_v1.sales_order_heading') . ':' ) !!}
            {!! Form::text('common_settings[sales_order_heading]', __('lang_v1.sales_order'), ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.sales_order_heading'), 'id' => 'sales_order_heading' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_no_prefix', __('invoice.invoice_no_prefix') . ':' ) !!}
            {!! Form::text('invoice_no_prefix', __('sale.invoice_no'), ['class' => 'form-control',
            'placeholder' => __('invoice.invoice_no_prefix') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('quotation_no_prefix', __('lang_v1.quotation_no_prefix') . ':' ) !!}
            {!! Form::text('quotation_no_prefix', __('lang_v1.quotation_no'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.quotation_no_prefix') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('date_label', __('lang_v1.date_label') . ':' ) !!}
            {!! Form::text('date_label', __('lang_v1.date'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.date_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('due_date_label', __('lang_v1.due_date_label') . ':' ) !!}
            {!! Form::text('common_settings[due_date_label]', __('lang_v1.due_date'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.due_date_label'), 'id' => 'due_date_label' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_due_date]', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_due_date')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('date_time_format', __('lang_v1.date_time_format') . ':' ) !!}
            {!! Form::text('date_time_format', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.date_time_format') ]); !!}
            <p class="help-block">{!! __('lang_v1.date_time_format_help') !!}</p>
          </div>
        </div>
        @php
        $sell_custom_field_1_label = !empty($custom_labels['sell']['custom_field_1']) ?
        $custom_labels['sell']['custom_field_1'] : '';

        $sell_custom_field_2_label = !empty($custom_labels['sell']['custom_field_2']) ?
        $custom_labels['sell']['custom_field_2'] : '';

        $sell_custom_field_3_label = !empty($custom_labels['sell']['custom_field_3']) ?
        $custom_labels['sell']['custom_field_3'] : '';

        $sell_custom_field_4_label = !empty($custom_labels['sell']['custom_field_4']) ?
        $custom_labels['sell']['custom_field_4'] : '';
        @endphp
        @if (!empty($sell_custom_field_1_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields1]', 1, false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['sell']['custom_field_1'] ?? __('lang_v1.product_custom_field1') }}</label>
            </div>
          </div>
        </div>
        @endif
        @if (!empty($sell_custom_field_2_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields2]', 1, false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['sell']['custom_field_2'] ?? __('lang_v1.product_custom_field2') }}</label>
            </div>
          </div>
        </div>
        @endif
        @if (!empty($sell_custom_field_3_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields3]', 1, false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['sell']['custom_field_3'] ?? __('lang_v1.product_custom_field3') }}</label>
            </div>
          </div>
        </div>
        @endif
        @if (!empty($sell_custom_field_4_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields4]', 1, false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['sell']['custom_field_4'] ?? __('lang_v1.product_custom_field4') }}</label>
            </div>
          </div>
        </div>
        @endif

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sales_person_label', __('lang_v1.sales_person_label') . ':' ) !!}
            {!! Form::text('sales_person_label', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sales_person_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('commission_agent_label', __('lang_v1.commission_agent_label') . ':' ) !!}
            {!! Form::text('commission_agent_label', __('lang_v1.commission_agent'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.commission_agent_label') ]); !!}
          </div>
        </div>

        <div class="clearfix"></div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_business_name', 1, false, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_business_name')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_location_name', 1, true, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_location_name')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_sales_person', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_sales_person')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_commission_agent', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_commission_agent')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-12">
          <h4>@lang('lang_v1.fields_for_customer_details'):</h4>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_customer', 1, true, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_customer')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('customer_label', __('invoice.customer_label') . ':' ) !!}
            {!! Form::text('customer_label', __('contact.customer'), ['class' => 'form-control',
            'placeholder' => __('invoice.customer_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_client_id', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_client_id')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('client_id_label', __('lang_v1.client_id_label') . ':' ) !!}
            {!! Form::text('client_id_label', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.client_id_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('client_tax_label', __('lang_v1.client_tax_label') . ':' ) !!}
            {!! Form::text('client_tax_label', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.client_tax_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_reward_point', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_reward_point')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field1', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['contact']['custom_field_1'] ?? __('lang_v1.contact_custom_field1') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field2', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['contact']['custom_field_2'] ?? __('lang_v1.contact_custom_field2') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field3', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['contact']['custom_field_3'] ?? __('lang_v1.contact_custom_field3') }}</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field4', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['contact']['custom_field_4'] ?? __('lang_v1.contact_custom_field4') }}</label>
            </div>
          </div>
        </div>
      </div>
      <div class="row hide-for-letterhead">
        <div class="col-sm-12">
          <h4>@lang('invoice.fields_to_be_shown_in_address'):</h4>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_landmark', 1, true, ['class' => 'input-icheck']); !!}
                @lang('business.landmark')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_city', 1, true, ['class' => 'input-icheck']); !!}
                @lang('business.city')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_state', 1, true, ['class' => 'input-icheck']); !!}
                @lang('business.state')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_country', 1, true, ['class' => 'input-icheck']); !!}
                @lang('business.country')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_zip_code', 1, true, ['class' => 'input-icheck']); !!}
                @lang('business.zip_code')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field1', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['location']['custom_field_1'] ?? __('lang_v1.location_custom_field1') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field2', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['location']['custom_field_2'] ?? __('lang_v1.location_custom_field2') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field3', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['location']['custom_field_3'] ?? __('lang_v1.location_custom_field3') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field4', false, ['class' => 'input-icheck']); !!}
                {{ $custom_labels['location']['custom_field_4'] ?? __('lang_v1.location_custom_field4') }}</label>
            </div>
          </div>
        </div>

        <div class="clearfix"></div>
        <!-- Shop Communication details -->
        <div class="col-sm-12">
          <h4>@lang('invoice.fields_to_shown_for_communication'):</h4>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_mobile_number', 1, true, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_mobile_number')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_alternate_number', 1, false, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_alternate_number')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_email', 1, false, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_email')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-12">
          <h4>@lang('invoice.fields_to_shown_for_tax'):</h4>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_tax_1', 1, true, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_tax_1')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_tax_2', 1, false, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_tax_2')</label>
            </div>
          </div>
        </div>

      </div>
    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_product_label', __('lang_v1.product_label') . ':' ) !!}
            {!! Form::text('table_product_label', __('sale.product'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.product_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_qty_label', __('lang_v1.qty_label') . ':' ) !!}
            {!! Form::text('table_qty_label', __('lang_v1.quantity'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.qty_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_unit_price_label', __('lang_v1.unit_price_label') . ':' ) !!}
            {!! Form::text('table_unit_price_label', __('sale.unit_price'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.unit_price_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_subtotal_label', __('lang_v1.subtotal_label') . ':' ) !!}
            {!! Form::text('table_subtotal_label', __('sale.subtotal'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.subtotal_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cat_code_label', __('lang_v1.cat_code_label') . ':' ) !!}
            {!! Form::text('cat_code_label', 'HSN', ['class' => 'form-control',
            'placeholder' => 'HSN or Category Code' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_quantity_label', __('lang_v1.total_quantity_label') . ':' ) !!}
            {!! Form::text('common_settings[total_quantity_label]', 'Total Quantity', ['class' => 'form-control',
            'placeholder' => __('lang_v1.total_quantity_label'), 'id' => 'total_quantity_label' ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('item_discount_label', __('lang_v1.item_discount_label') . ':' ) !!}
            {!! Form::text('common_settings[item_discount_label]', 'Discount', ['class' => 'form-control',
            'placeholder' => __('lang_v1.item_discount_label'), 'id' => 'item_discount_label' ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('discounted_unit_price_label', __('lang_v1.discounted_unit_price_label') . ':' ) !!}
            {!! Form::text('common_settings[discounted_unit_price_label]', 'Price after discount', ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.discounted_unit_price_label'), 'id' => 'discounted_unit_price_label' ]); !!}
          </div>
        </div>

        <div class="col-sm-12">
          <h4>@lang('lang_v1.product_details_to_be_shown'):</h4>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_brand', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_brand')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_sku', 1, true, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_sku')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_cat_code', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_cat_code')</label>
            </div>
          </div>
        </div>



        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_sale_description', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_sale_description')</label>
            </div>
            <p class="help-block">@lang('lang_v1.product_imei_or_sn')</p>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_product_description]', 1, false, ['class' => 'input-icheck']);
                !!} @lang('lang_v1.show_product_description')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field1', false, ['class' =>
                'input-icheck']); !!} {{ $custom_labels['product']['custom_field_1'] ??
                __('lang_v1.product_custom_field1') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field2', false, ['class' =>
                'input-icheck']); !!} {{ $custom_labels['product']['custom_field_2'] ??
                __('lang_v1.product_custom_field2') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field3', false, ['class' =>
                'input-icheck']); !!} {{ $custom_labels['product']['custom_field_3'] ??
                __('lang_v1.product_custom_field3') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field4', false, ['class' =>
                'input-icheck']); !!} {{ $custom_labels['product']['custom_field_4'] ??
                __('lang_v1.product_custom_field4') }}</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        @if(request()->session()->get('business.enable_product_expiry') == 1)
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_expiry', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_product_expiry')</label>
            </div>
          </div>
        </div>
        @endif
        @if(request()->session()->get('business.enable_lot_number') == 1)
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_lot', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_lot_number')</label>
            </div>
          </div>
        </div>
        @endif

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_image', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_product_image')</label>
            </div>
          </div>
        </div>

        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_warranty_name]', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_warranty_name')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_warranty_exp_date]', 1, false, ['class' => 'input-icheck']);
                !!} @lang('lang_v1.show_warranty_exp_date')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_warranty_description]', 1, false, ['class' => 'input-icheck']);
                !!} @lang('lang_v1.show_warranty_description')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_base_unit_details]', 1, false, ['class' => 'input-icheck']);
                !!} @lang('lang_v1.show_base_unit_details')</label>
            </div>
          </div>
        </div>

      </div>
    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_total_label', __('invoice.sub_total_label') . ':' ) !!}
            {!! Form::text('sub_total_label', __('sale.subtotal'), ['class' => 'form-control',
            'placeholder' => __('invoice.sub_total_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('discount_label', __('invoice.discount_label') . ':' ) !!}
            {!! Form::text('discount_label', __('sale.discount'), ['class' => 'form-control',
            'placeholder' => __('invoice.discount_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('tax_label', __('invoice.tax_label') . ':' ) !!}
            {!! Form::text('tax_label', __('sale.tax'), ['class' => 'form-control',
            'placeholder' => __('invoice.tax_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_label', __('invoice.total_label') . ':' ) !!}
            {!! Form::text('total_label', __('sale.total'), ['class' => 'form-control',
            'placeholder' => __('invoice.total_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_items_label', __('lang_v1.total_items_label') . ':' ) !!}
            {!! Form::text('common_settings[total_items_label]', null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.total_items_label'), 'id' => 'total_items_label' ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('round_off_label', __('lang_v1.round_off_label') . ':' ) !!}
            {!! Form::text('round_off_label', __('lang_v1.round_off'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.round_off_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_due_label', __('invoice.total_due_label') . ' (' . __('lang_v1.current_sale') . '):'
            ) !!}
            {!! Form::text('total_due_label', __('report.total_due'), ['class' => 'form-control',
            'placeholder' => __('invoice.total_due_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('paid_label', __('invoice.paid_label') . ':' ) !!}
            {!! Form::text('paid_label', __('sale.total_paid'), ['class' => 'form-control',
            'placeholder' => __('invoice.paid_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_payments', 1, true, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_payments')</label>
            </div>
          </div>
        </div>
        <!-- Barcode -->
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_barcode', 1, false, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_barcode')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('prev_bal_label', __('invoice.total_due_label') . ' (' . __('lang_v1.all_sales') . '):' )
            !!}
            {!! Form::text('prev_bal_label', '', ['class' => 'form-control',
            'placeholder' => __('invoice.total_due_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-5">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_previous_bal', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_previous_bal_due')</label>
              @show_tooltip(__('lang_v1.previous_bal_due_help'))
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('change_return_label', __('lang_v1.change_return_label') . ':' ) !!}
            @show_tooltip(__('lang_v1.change_return_help'))
            {!! Form::text('change_return_label', __('lang_v1.change_return'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.change_return_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3 hide" id="hide_price_div">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[hide_price]', 1, false, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.hide_all_prices')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <label>
              {!! Form::checkbox('common_settings[show_total_in_words]', 1, false, ['class' => 'input-icheck']); !!}
              @lang('lang_v1.show_total_in_words')</label> @show_tooltip(__('lang_v1.show_in_word_help'))
            @if(!extension_loaded('intl'))
            <p class="help-block">@lang('lang_v1.enable_php_intl_extension')</p>
            @endif
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('word_format', __('lang_v1.word_format') . ':') !!}
            @show_tooltip(__('lang_v1.word_format_help'))
            {!! Form::select('common_settings[num_to_word_format]', ['international' => __('lang_v1.international'),
            'indian' => __('lang_v1.indian')], 'international', ['class' => 'form-control', 'id' => 'word_format']); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('tax_summary_label', __('lang_v1.tax_summary_label') . ':' ) !!}
            {!! Form::text('common_settings[tax_summary_label]', '', ['class' => 'form-control', 'placeholder' =>
            __('lang_v1.tax_summary_label'), 'id' => 'tax_summary_label' ]); !!}
          </div>
        </div>




      </div>
    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-6 hide">
          <div class="form-group">
            {!! Form::label('highlight_color', __('invoice.highlight_color') . ':' ) !!}
            {!! Form::text('highlight_color', '#000000', ['class' => 'form-control',
            'placeholder' => __('invoice.highlight_color') ]); !!}
          </div>
        </div>

        <div class="clearfix"></div>
        <div class="col-md-12 hide">
          <hr />
        </div>

        <div class="col-sm-12">
          <div class="form-group">
            {!! Form::label('footer_text', __('invoice.footer_text') . ':' ) !!}
            {!! Form::textarea('footer_text', null, ['class' => 'form-control',
            'placeholder' => __('invoice.footer_text'), 'rows' => 3]); !!}
          </div>
        </div>
        <div class="col-sm-6">
          <div class="form-group">
            <br>
            <div class="checkbox">
              <label>
                {!! Form::checkbox('is_default', 1, false, ['class' => 'input-icheck']); !!}
                @lang('barcode.set_as_default')</label>
            </div>
          </div>
        </div>
      </div>
    </div>
  </div>
  @component('components.widget', ['class' => 'box-solid', 'title' => __('lang_v1.qr_code')])
  <div class="row">
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('show_qr_code', 1, false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.show_qr_code')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('common_settings[show_qr_code_label]', 1, false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.show_labels')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('common_settings[zatca_qr]', 1, false, ['class' => 'input-icheck', 'id' => 'zatca_qr']);
            !!} @lang('lang_v1.zatca_qr')</label>
          @show_tooltip(__('lang_v1.zatca_qr_help'))
        </div>
      </div>
    </div>
    <div class="col-sm-4" id="zatca_phase_container" style="display: none;">
      <div class="form-group">
        {!! Form::label('zatca_phase', __('lang_v1.zatca_phase') . ':*') !!}
        {!! Form::select('common_settings[zatca_phase]', [
        'phase_1' => __('lang_v1.zatca_phase1'),
        'phase_2' => __('lang_v1.zatca_phase2'),
        ],$invoice_layout->common_settings['zatca_phase'] ?? null , ['class' => 'form-control', 'id' => 'zatca_phase']);
        !!}
        <small id="phase2_message" style="display: none; color: green; font-size: 12px;">
          {{ __('lang_v1.phase2_message') }}
        </small>
      </div>
    </div>
    <div class="clearfix"></div>
    <div class="col-md-12">
      <h4>@lang('lang_v1.fields_to_be_shown'):</h4>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'business_name', false, ['class' => 'input-icheck']); !!}
            @lang('business.business_name')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'address', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.business_location_address')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'tax_1', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.business_tax_1')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'tax_2', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.business_tax_2')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'invoice_no', false, ['class' => 'input-icheck']); !!}
            @lang('sale.invoice_no')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'invoice_datetime', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.invoice_datetime')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'subtotal', false, ['class' => 'input-icheck']); !!}
            @lang('sale.subtotal')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'total_amount', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.total_amount_with_tax')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'total_tax', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.total_tax')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'customer_name', false, ['class' => 'input-icheck']); !!}
            @lang('sale.customer_name')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'invoice_url', false, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.view_invoice_url')</label>
        </div>
      </div>
    </div>
  </div>
  @endcomponent

  @if(!empty($enabled_modules) && in_array('types_of_service', $enabled_modules) )
  @include('types_of_service.invoice_layout_settings')
  @endif

  <!-- Call restaurant module if defined -->
  @include('restaurant.partials.invoice_layout')

  @if(Module::has('Repair'))
  @include('repair::layouts.partials.invoice_layout_settings')
  @endif
  <div class="box box-solid">
    <div class="box-header with-border">
      <h3 class="box-title">@lang('lang_v1.layout_credit_note')</h3>
    </div>

    <div class="box-body">
      <div class="row">

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cn_heading', __('lang_v1.cn_heading') . ':' ) !!}
            {!! Form::text('cn_heading', 'Credit Note', ['class' => 'form-control',
            'placeholder' => __('lang_v1.cn_heading') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cn_no_label', __('lang_v1.cn_no_label') . ':' ) !!}
            {!! Form::text('cn_no_label', __('purchase.ref_no'), ['class' => 'form-control',
            'placeholder' => __('lang_v1.cn_no_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cn_amount_label', __('lang_v1.cn_amount_label') . ':' ) !!}
            {!! Form::text('cn_amount_label', 'Credit Amount', ['class' => 'form-control', 'placeholder' =>
            __('lang_v1.cn_amount_label') ]); !!}
          </div>
        </div>

      </div>
    </div>
  </div>

  <div class="row">
    <div class="col-sm-12 text-center">
      <button type="submit"
        class="tw-dw-btn tw-dw-btn-primary tw-text-white tw-dw-btn-lg">@lang('messages.save')</button>
    </div>
  </div>

  {!! Form::close() !!}
</section>
<!-- /.content -->
@stop
@section('javascript')
<script type="text/javascript">
  __page_leave_confirmation('#add_invoice_layout_form');
    $(document).on('ifChanged', '#show_letter_head', function() {
        letter_head_changed();
    });

    function letter_head_changed() {
        if($('#show_letter_head').is(":checked")) {
            $('.hide-for-letterhead').addClass('hide');
            $('.letter_head_input').removeClass('hide');
        } else {
            $('.hide-for-letterhead').removeClass('hide');
            $('.letter_head_input').addClass('hide');
        }
    }
</script>
<script>
  $(document).ready(function () {
      function toggleZatcaPhase() {
          if ($('#zatca_qr').is(':checked')) {
              $('#zatca_phase_container').fadeIn();
          } else {
              $('#zatca_phase_container').fadeOut();
          }
      }

      function checkPhaseSelection(){
        if ($('#zatca_phase').val() === 'phase_2') {
            $('#phase2_message').fadeIn();
        } else {
            $('#phase2_message').fadeOut();
        }
      }
      // $(document).on('change', '#zatca_qr', function () {
      //       toggleZatcaPhase();
      // });

      $('#zatca_qr').on('ifChanged', function(event){
        //Check if checkbox is checked or not
        toggleZatcaPhase()
      });


      $('#zatca_phase').on('change', function () {
        checkPhaseSelection();
      });
  });
</script>
@endsection

Add Watermark Section to Edit Form

In your invoice layout edit form (typically resources/views/invoice_layout/edit.blade.php), add the watermark settings section:

@extends('layouts.app')
@section('title', __('invoice.edit_invoice_layout'))

@section('content')
<style type="text/css">



</style>
<!-- Content Header (Page header) -->
<section class="content-header">
  <h1 class="tw-text-xl md:tw-text-3xl tw-font-bold tw-text-black">@lang('invoice.edit_invoice_layout')</h1>
</section>

<!-- Main content -->
<section class="content">
  {!! Form::open(['url' => action([\App\Http\Controllers\InvoiceLayoutController::class, 'update'],
  [$invoice_layout->id]), 'method' => 'put',
  'id' => 'add_invoice_layout_form', 'files' => true]) !!}

  @php
  $product_custom_fields = !empty($invoice_layout->product_custom_fields) ? $invoice_layout->product_custom_fields : [];
  $contact_custom_fields = !empty($invoice_layout->contact_custom_fields) ? $invoice_layout->contact_custom_fields : [];
  $location_custom_fields = !empty($invoice_layout->location_custom_fields) ? $invoice_layout->location_custom_fields :
  [];
  $custom_labels = json_decode(session('business.custom_labels'), true);
  @endphp
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">

        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('name', __('invoice.layout_name') . ':*') !!}
            {!! Form::text('name', $invoice_layout->name, ['class' => 'form-control', 'required',
            'placeholder' => __('invoice.layout_name')]); !!}
          </div>
        </div>

        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('design', __('lang_v1.design') . ':*') !!}
            {!! Form::select('design', $designs, $invoice_layout->design, ['class' => 'form-control']); !!}
            <span class="help-block">
              @lang('lang_v1.used_for_browser_based_printing')
            </span>
          </div>

          <div class="form-group @if($invoice_layout->design != 'columnize-taxes') hide @endif" id="columnize-taxes">
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" required="required"
                placeholder="tax 1 name" value="{{$invoice_layout->table_tax_headings[0]}}" @if($invoice_layout->design
              != 'columnize-taxes') disabled @endif>
              @show_tooltip(__('lang_v1.tooltip_columnize_taxes_heading'))
            </div>
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" placeholder="tax 2 name"
                value="{{$invoice_layout->table_tax_headings[1]}}" @if($invoice_layout->design != 'columnize-taxes')
              disabled @endif>
            </div>
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" placeholder="tax 3 name"
                value="{{$invoice_layout->table_tax_headings[2]}}" @if($invoice_layout->design != 'columnize-taxes')
              disabled @endif>
            </div>
            <div class="col-md-3">
              <input type="text" class="form-control" name="table_tax_headings[]" placeholder="tax 4 name"
                value="{{$invoice_layout->table_tax_headings[3]}}" @if($invoice_layout->design != 'columnize-taxes')
              disabled @endif>
            </div>

          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-6">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_letter_head', 1, $invoice_layout->show_letter_head,
                ['class' => 'input-icheck', 'id' => 'show_letter_head']); !!}
                @lang('lang_v1.show_letter_head')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-6 letter_head_input">
          <div class="form-group">
            {!! Form::label('letter_head', __('lang_v1.letter_head') . ':') !!}
            {!! Form::file('letter_head', ['accept' => 'image/*']); !!}
            <span class="help-block">@lang('lang_v1.letter_head_help') <br> @lang('lang_v1.invoice_logo_help',
              ['max_size' => '1 MB']) <br> @lang('lang_v1.letter_head_help2')</span>
          </div>
        </div>
      </div>
      <div class="row hide-for-letterhead">
        <!-- Logo -->
        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('logo', __('invoice.invoice_logo') . ':') !!}
            {!! Form::file('logo', ['accept' => 'image/*']); !!}
            <span class="help-block">@lang('lang_v1.invoice_logo_help', ['max_size' => '1 MB'])<br>
              @lang('lang_v1.invoice_logo_help2')</span>
          </div>
        </div>
        <div class="col-sm-6">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_logo', 1, $invoice_layout->show_logo, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_logo')</label>
            </div>
          </div>
        </div>





        <div class="col-sm-12">
          <div class="form-group">
            {!! Form::label('header_text', __('invoice.header_text') . ':' ) !!}
            {!! Form::textarea('header_text', $invoice_layout->header_text, ['class' => 'form-control',
            'placeholder' => __('invoice.header_text'), 'rows' => 3]); !!}
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line1', __('lang_v1.sub_heading_line', ['_number_' => 1]) . ':' ) !!}
            {!! Form::text('sub_heading_line1', $invoice_layout->sub_heading_line1, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 1]) ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line2', __('lang_v1.sub_heading_line', ['_number_' => 2]) . ':' ) !!}
            {!! Form::text('sub_heading_line2', $invoice_layout->sub_heading_line2, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 2]) ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line3', __('lang_v1.sub_heading_line', ['_number_' => 3]) . ':' ) !!}
            {!! Form::text('sub_heading_line3', $invoice_layout->sub_heading_line3, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 3]) ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line4', __('lang_v1.sub_heading_line', ['_number_' => 4]) . ':' ) !!}
            {!! Form::text('sub_heading_line4', $invoice_layout->sub_heading_line4, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 4]) ]); !!}
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_heading_line5', __('lang_v1.sub_heading_line', ['_number_' => 5]) . ':' ) !!}
            {!! Form::text('sub_heading_line5', $invoice_layout->sub_heading_line5, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sub_heading_line', ['_number_' => 5]) ]); !!}
          </div>
        </div>
      </div>
    </div>
  </div>




  <div class="box box-solid">
    <div class="box-body">
      <div class="row">

        <!-- Watermark Settings Section -->
        <div class="col-sm-12">
          <h4>@lang('lang_v1.watermark_settings'):</h4>
        </div>

        <div class="col-sm-6">
          <div class="form-group">
            {!! Form::label('watermark_logo', __('lang_v1.watermark_logo') . ':') !!}
            {!! Form::file('watermark_logo', ['accept' => 'image/*']); !!}
            <span class="help-block">@lang('lang_v1.watermark_logo_help', ['max_size' => '1 MB'])</span>
            @if(!empty($invoice_layout->watermark_logo))
            <div class="current_logo">
              <img src="{{asset('uploads/invoice_logos/' . $invoice_layout->watermark_logo)}}" alt="Current Watermark"
                style="max-height: 80px; width: auto;">
              <br><small>@lang('lang_v1.current_watermark')</small>
            </div>
            @endif
          </div>
        </div>

        <div class="col-sm-6">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_watermark', 1, $invoice_layout->show_watermark, ['class' =>
                'input-icheck']);
                !!} @lang('lang_v1.show_watermark')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_width', __('lang_v1.watermark_width') . ':') !!}
            {!! Form::number('watermark_width', $invoice_layout->watermark_width ?? 300, ['class' =>
            'form-control',
            'min' => '50', 'max' => '800', 'placeholder' => '300']); !!}
            <span class="help-block">@lang('lang_v1.width_in_pixels')</span>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_height', __('lang_v1.watermark_height') . ':') !!}
            {!! Form::number('watermark_height', $invoice_layout->watermark_height ?? 300, ['class' =>
            'form-control',
            'min' => '50', 'max' => '800', 'placeholder' => '300']); !!}
            <span class="help-block">@lang('lang_v1.height_in_pixels')</span>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_opacity', __('lang_v1.watermark_opacity') . ':') !!}
            {!! Form::select('watermark_opacity', [
            '0.05' => '5%',
            '0.1' => '10%',
            '0.15' => '15%',
            '0.2' => '20%',
            '0.25' => '25%',
            '0.3' => '30%'
            ], $invoice_layout->watermark_opacity ?? '0.1', ['class' => 'form-control']); !!}
            <span class="help-block">@lang('lang_v1.transparency_level')</span>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('watermark_position', __('lang_v1.watermark_position') . ':') !!}
            {!! Form::select('watermark_position', [
            'center' => __('lang_v1.center'),
            'top-left' => __('lang_v1.top_left'),
            'top-right' => __('lang_v1.top_right'),
            'bottom-left' => __('lang_v1.bottom_left'),
            'bottom-right' => __('lang_v1.bottom_right')
            ], $invoice_layout->watermark_position ?? 'center', ['class' => 'form-control']); !!}
          </div>
        </div>
      </div>
    </div>
  </div>


  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_heading', __('invoice.invoice_heading') . ':' ) !!}
            {!! Form::text('invoice_heading', $invoice_layout->invoice_heading, ['class' => 'form-control',
            'placeholder' => __('invoice.invoice_heading') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_heading_not_paid', __('invoice.invoice_heading_not_paid') . ':' ) !!}
            {!! Form::text('invoice_heading_not_paid', $invoice_layout->invoice_heading_not_paid, ['class' =>
            'form-control',
            'placeholder' => __('invoice.invoice_heading_not_paid') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_heading_paid', __('invoice.invoice_heading_paid') . ':' ) !!}
            {!! Form::text('invoice_heading_paid', $invoice_layout->invoice_heading_paid, ['class' =>
            'form-control',
            'placeholder' => __('invoice.invoice_heading_paid') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('proforma_heading', __('lang_v1.proforma_heading') . ':' ) !!}
            @show_tooltip(__('lang_v1.tooltip_proforma_heading'))
            {!! Form::text('common_settings[proforma_heading]',
            !empty($invoice_layout->common_settings['proforma_heading']) ?
            $invoice_layout->common_settings['proforma_heading'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.proforma_heading'), 'id' => 'proforma_heading' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('quotation_heading', __('lang_v1.quotation_heading') . ':' )
            !!}@show_tooltip(__('lang_v1.tooltip_quotation_heading'))
            {!! Form::text('quotation_heading', $invoice_layout->quotation_heading, ['class' => 'form-control',
            'placeholder' => __('lang_v1.quotation_heading') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sales_order_heading', __('lang_v1.sales_order_heading') . ':' ) !!}
            {!! Form::text('common_settings[sales_order_heading]',
            !empty($invoice_layout->common_settings['sales_order_heading']) ?
            $invoice_layout->common_settings['sales_order_heading'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sales_order_heading'), 'id' => 'sales_order_heading' ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('invoice_no_prefix', __('invoice.invoice_no_prefix') . ':' ) !!}
            {!! Form::text('invoice_no_prefix', $invoice_layout->invoice_no_prefix, ['class' => 'form-control',
            'placeholder' => __('invoice.invoice_no_prefix') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('quotation_no_prefix', __('lang_v1.quotation_no_prefix') . ':' ) !!}
            {!! Form::text('quotation_no_prefix', $invoice_layout->quotation_no_prefix, ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.quotation_no_prefix') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('date_label', __('lang_v1.date_label') . ':' ) !!}
            {!! Form::text('date_label', $invoice_layout->date_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.date_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('due_date_label', __('lang_v1.due_date_label') . ':' ) !!}
            {!! Form::text('common_settings[due_date_label]',
            !empty($invoice_layout->common_settings['due_date_label'])
            ? $invoice_layout->common_settings['due_date_label'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.due_date_label'), 'id' => 'due_date_label' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_due_date]', 1,
                !empty($invoice_layout->common_settings['show_due_date']), ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_due_date')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('date_time_format', __('lang_v1.date_time_format') . ':' ) !!}
            {!! Form::text('date_time_format', $invoice_layout->date_time_format, ['class' => 'form-control',
            'placeholder' => __('lang_v1.date_time_format') ]); !!}
            <p class="help-block">{!! __('lang_v1.date_time_format_help') !!}</p>
          </div>
        </div>
        @php
        $sell_custom_field_1_label = !empty($custom_labels['sell']['custom_field_1']) ?
        $custom_labels['sell']['custom_field_1'] : '';

        $sell_custom_field_2_label = !empty($custom_labels['sell']['custom_field_2']) ?
        $custom_labels['sell']['custom_field_2'] : '';

        $sell_custom_field_3_label = !empty($custom_labels['sell']['custom_field_3']) ?
        $custom_labels['sell']['custom_field_3'] : '';

        $sell_custom_field_4_label = !empty($custom_labels['sell']['custom_field_4']) ?
        $custom_labels['sell']['custom_field_4'] : '';
        @endphp
        @if (!empty($sell_custom_field_1_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields1]', 1,
                !empty($invoice_layout->common_settings['sell_custom_fields1']), ['class' => 'input-icheck']); !!}
                {{
                $custom_labels['sell']['custom_field_1'] ?? __('lang_v1.product_custom_field1') }}</label>
            </div>
          </div>
        </div>
        @endif
        @if (!empty($sell_custom_field_2_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields2]', 1,
                !empty($invoice_layout->common_settings['sell_custom_fields2']), ['class' => 'input-icheck']); !!}
                {{
                $custom_labels['sell']['custom_field_2'] ?? __('lang_v1.product_custom_field2') }}</label>
            </div>
          </div>
        </div>
        @endif
        @if (!empty($sell_custom_field_3_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields3]', 1,
                !empty($invoice_layout->common_settings['sell_custom_fields3']), ['class' => 'input-icheck']); !!}
                {{
                $custom_labels['sell']['custom_field_3'] ?? __('lang_v1.product_custom_field3') }}</label>
            </div>
          </div>
        </div>
        @endif
        @if (!empty($sell_custom_field_4_label))
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[sell_custom_fields4]', 1,
                !empty($invoice_layout->common_settings['sell_custom_fields4']), ['class' => 'input-icheck']); !!}
                {{
                $custom_labels['sell']['custom_field_4'] ?? __('lang_v1.product_custom_field4') }}</label>
            </div>
          </div>
        </div>
        @endif
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sales_person_label', __('lang_v1.sales_person_label') . ':' ) !!}
            {!! Form::text('sales_person_label', $invoice_layout->sales_person_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.sales_person_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('commission_agent_label', __('lang_v1.commission_agent_label') . ':' ) !!}
            {!! Form::text('commission_agent_label', $invoice_layout->commission_agent_label, ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.commission_agent_label') ]); !!}
          </div>
        </div>
        <div class="clearfix"></div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_business_name', 1, $invoice_layout->show_business_name, ['class' =>
                'input-icheck']); !!} @lang('invoice.show_business_name')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_location_name', 1, $invoice_layout->show_location_name, ['class' =>
                'input-icheck']); !!} @lang('invoice.show_location_name')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_sales_person', 1, $invoice_layout->show_sales_person, ['class' =>
                'input-icheck']); !!} @lang('lang_v1.show_sales_person')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_commission_agent', 1, $invoice_layout->show_commission_agent, ['class' =>
                'input-icheck']); !!} @lang('lang_v1.show_commission_agent')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-12">
          <h4>@lang('lang_v1.fields_for_customer_details'):</h4>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_customer', 1, $invoice_layout->show_customer, ['class' =>
                'input-icheck']); !!}
                @lang('invoice.show_customer')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('customer_label', __('invoice.customer_label') . ':' ) !!}
            {!! Form::text('customer_label', $invoice_layout->customer_label, ['class' => 'form-control',
            'placeholder' => __('invoice.customer_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_client_id', 1, $invoice_layout->show_client_id, ['class' =>
                'input-icheck']);
                !!} @lang('lang_v1.show_client_id')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('client_id_label', __('lang_v1.client_id_label') . ':' ) !!}
            {!! Form::text('client_id_label', $invoice_layout->client_id_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.client_id_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('client_tax_label', __('lang_v1.client_tax_label') . ':' ) !!}
            {!! Form::text('client_tax_label', $invoice_layout->client_tax_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.client_tax_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_reward_point', 1, $invoice_layout->show_reward_point, ['class' =>
                'input-icheck']); !!} @lang('lang_v1.show_reward_point')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field1', in_array('custom_field1',
                $contact_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['contact']['custom_field_1'] ?? __('lang_v1.contact_custom_field1') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field2', in_array('custom_field2',
                $contact_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['contact']['custom_field_2'] ?? __('lang_v1.contact_custom_field2') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field3', in_array('custom_field3',
                $contact_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['contact']['custom_field_3'] ?? __('lang_v1.contact_custom_field3') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('contact_custom_fields[]', 'custom_field4', in_array('custom_field4',
                $contact_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['contact']['custom_field_4'] ?? __('lang_v1.contact_custom_field4') }}</label>
            </div>
          </div>
        </div>

      </div>
      <div class="row hide-for-letterhead">
        <div class="col-sm-12">
          <h4>@lang('invoice.fields_to_be_shown_in_address'):</h4>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_landmark', 1, $invoice_layout->show_landmark, ['class' =>
                'input-icheck']); !!}
                @lang('business.landmark')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_city', 1, $invoice_layout->show_city, ['class' => 'input-icheck']); !!}
                @lang('business.city')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_state', 1, $invoice_layout->show_state, ['class' => 'input-icheck']); !!}
                @lang('business.state')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_country', 1, $invoice_layout->show_country, ['class' => 'input-icheck']);
                !!}
                @lang('business.country')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_zip_code', 1, $invoice_layout->show_zip_code, ['class' =>
                'input-icheck']); !!}
                @lang('business.zip_code')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field1', in_array('custom_field1',
                $location_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['location']['custom_field_1'] ?? __('lang_v1.location_custom_field1') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field2', in_array('custom_field2',
                $location_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['location']['custom_field_2'] ?? __('lang_v1.location_custom_field2') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field3', in_array('custom_field3',
                $location_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['location']['custom_field_3'] ?? __('lang_v1.location_custom_field3') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('location_custom_fields[]', 'custom_field4', in_array('custom_field4',
                $location_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['location']['custom_field_4'] ?? __('lang_v1.location_custom_field4') }}</label>
            </div>
          </div>
        </div>
        <div class="col-sm-12">
          <div class="form-group">
            <label>@lang('invoice.fields_to_shown_for_communication'):</label>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_mobile_number', 1, $invoice_layout->show_mobile_number, ['class' =>
                'input-icheck']); !!} @lang('invoice.show_mobile_number')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_alternate_number', 1, $invoice_layout->show_alternate_number, ['class' =>
                'input-icheck']); !!} @lang('invoice.show_alternate_number')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_email', 1, $invoice_layout->show_email, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_email')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-12">
          <div class="form-group">
            <label>@lang('invoice.fields_to_shown_for_tax'):</label>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_tax_1', 1, $invoice_layout->show_tax_1, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_tax_1')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_tax_2', 1, $invoice_layout->show_tax_2, ['class' => 'input-icheck']); !!}
                @lang('invoice.show_tax_2')</label>
            </div>
          </div>
        </div>
      </div>
    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_product_label', __('lang_v1.product_label') . ':' ) !!}
            {!! Form::text('table_product_label', $invoice_layout->table_product_label, ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.product_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_qty_label', __('lang_v1.qty_label') . ':' ) !!}
            {!! Form::text('table_qty_label', $invoice_layout->table_qty_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.qty_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_unit_price_label', __('lang_v1.unit_price_label') . ':' ) !!}
            {!! Form::text('table_unit_price_label', $invoice_layout->table_unit_price_label, ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.unit_price_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('table_subtotal_label', __('lang_v1.subtotal_label') . ':' ) !!}
            {!! Form::text('table_subtotal_label', $invoice_layout->table_subtotal_label, ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.subtotal_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cat_code_label', __('lang_v1.cat_code_label') . ':' ) !!}
            {!! Form::text('cat_code_label', $invoice_layout->cat_code_label, ['class' => 'form-control',
            'placeholder'
            => 'HSN or Category Code' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_quantity_label', __('lang_v1.total_quantity_label') . ':' ) !!}
            {!! Form::text('common_settings[total_quantity_label]',
            !empty($invoice_layout->common_settings['total_quantity_label']) ?
            $invoice_layout->common_settings['total_quantity_label'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.total_quantity_label'), 'id' => 'total_quantity_label' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('item_discount_label', __('lang_v1.item_discount_label') . ':' ) !!}
            {!! Form::text('common_settings[item_discount_label]',
            !empty($invoice_layout->common_settings['item_discount_label']) ?
            $invoice_layout->common_settings['item_discount_label'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.item_discount_label'), 'id' => 'item_discount_label' ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('discounted_unit_price_label', __('lang_v1.discounted_unit_price_label') . ':' ) !!}
            {!! Form::text('common_settings[discounted_unit_price_label]',
            !empty($invoice_layout->common_settings['discounted_unit_price_label']) ?
            $invoice_layout->common_settings['discounted_unit_price_label'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.discounted_unit_price_label'), 'id' => 'discounted_unit_price_label' ]);
            !!}
          </div>
        </div>

        <div class="col-sm-12">
          <h4>@lang('lang_v1.product_details_to_be_shown'):</h4>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_brand', 1, $invoice_layout->show_brand, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_brand')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_sku', 1, $invoice_layout->show_sku, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_sku')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_cat_code', 1, $invoice_layout->show_cat_code, ['class' =>
                'input-icheck']); !!}
                @lang('lang_v1.show_cat_code')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_sale_description', 1, $invoice_layout->show_sale_description, ['class' =>
                'input-icheck']); !!} @lang('lang_v1.show_sale_description')</label>
            </div>
            <p class="help-block">@lang('lang_v1.product_imei_or_sn')</p>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_product_description]', 1,
                !empty($invoice_layout->common_settings['show_product_description']), ['class' =>
                'input-icheck']); !!}
                @lang('lang_v1.show_product_description')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field1',
                in_array('product_custom_field1',
                $product_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['product']['custom_field_1'] ?? __('lang_v1.product_custom_field1') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field2',
                in_array('product_custom_field2',
                $product_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['product']['custom_field_2'] ?? __('lang_v1.product_custom_field2') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field3',
                in_array('product_custom_field3',
                $product_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['product']['custom_field_3'] ?? __('lang_v1.product_custom_field3') }}</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('product_custom_fields[]', 'product_custom_field4',
                in_array('product_custom_field4',
                $product_custom_fields), ['class' => 'input-icheck']); !!} {{
                $custom_labels['product']['custom_field_4'] ?? __('lang_v1.product_custom_field4') }}</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        @if(request()->session()->get('business.enable_product_expiry') == 1)
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_expiry', 1, $invoice_layout->show_expiry, ['class' => 'input-icheck']);
                !!}
                @lang('lang_v1.show_product_expiry')</label>
            </div>
          </div>
        </div>
        @endif
        @if(request()->session()->get('business.enable_lot_number') == 1)
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_lot', 1, $invoice_layout->show_lot, ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_lot_number')</label>
            </div>
          </div>
        </div>
        @endif

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_image', 1, !empty($invoice_layout->show_image), ['class' =>
                'input-icheck']);
                !!} @lang('lang_v1.show_product_image')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_warranty_name]', 1,
                !empty($invoice_layout->common_settings['show_warranty_name']), ['class' => 'input-icheck']); !!}
                @lang('lang_v1.show_warranty_name')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_warranty_exp_date]', 1,
                !empty($invoice_layout->common_settings['show_warranty_exp_date']), ['class' => 'input-icheck']);
                !!}
                @lang('lang_v1.show_warranty_exp_date')</label>
            </div>
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_warranty_description]', 1,
                !empty($invoice_layout->common_settings['show_warranty_description']), ['class' =>
                'input-icheck']); !!}
                @lang('lang_v1.show_warranty_description')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[show_base_unit_details]', 1,
                !empty($invoice_layout->common_settings['show_base_unit_details']), ['class' => 'input-icheck']);
                !!}
                @lang('lang_v1.show_base_unit_details')</label>
            </div>
          </div>
        </div>

      </div>

    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('sub_total_label', __('invoice.sub_total_label') . ':' ) !!}
            {!! Form::text('sub_total_label', $invoice_layout->sub_total_label, ['class' => 'form-control',
            'placeholder' => __('invoice.sub_total_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('discount_label', __('invoice.discount_label') . ':' ) !!}
            {!! Form::text('discount_label', $invoice_layout->discount_label, ['class' => 'form-control',
            'placeholder' => __('invoice.discount_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('tax_label', __('invoice.tax_label') . ':' ) !!}
            {!! Form::text('tax_label', $invoice_layout->tax_label, ['class' => 'form-control',
            'placeholder' => __('invoice.tax_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_label', __('invoice.total_label') . ':' ) !!}
            {!! Form::text('total_label', $invoice_layout->total_label, ['class' => 'form-control',
            'placeholder' => __('invoice.total_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_items_label', __('lang_v1.total_items_label') . ':' ) !!}
            {!! Form::text('common_settings[total_items_label]',
            !empty($invoice_layout->common_settings['total_items_label']) ?
            $invoice_layout->common_settings['total_items_label'] : null, ['class' => 'form-control',
            'placeholder' => __('lang_v1.total_items_label'), 'id' => 'total_items_label' ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('round_off_label', __('lang_v1.round_off_label') . ':' ) !!}
            {!! Form::text('round_off_label', $invoice_layout->round_off_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.round_off_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('total_due_label', __('invoice.total_due_label') . ' (' . __('lang_v1.current_sale') .
            '):'
            ) !!}
            {!! Form::text('total_due_label', $invoice_layout->total_due_label, ['class' => 'form-control',
            'placeholder' => __('invoice.total_due_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('paid_label', __('invoice.paid_label') . ':' ) !!}
            {!! Form::text('paid_label', $invoice_layout->paid_label, ['class' => 'form-control',
            'placeholder' => __('invoice.paid_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_payments', 1, $invoice_layout->show_payments, ['class' =>
                'input-icheck']); !!}
                @lang('invoice.show_payments')</label>
            </div>
          </div>
        </div>

        <!-- Barcode -->
        <div class="col-sm-3">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_barcode', 1, $invoice_layout->show_barcode, ['class' => 'input-icheck']);
                !!}
                @lang('invoice.show_barcode')</label>
            </div>
          </div>
        </div>
        <div class="clearfix"></div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('prev_bal_label', __('invoice.total_due_label') . ' (' . __('lang_v1.all_sales') .
            '):' )
            !!}
            {!! Form::text('prev_bal_label', $invoice_layout->prev_bal_label, ['class' => 'form-control',
            'placeholder' => __('invoice.total_due_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-5">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('show_previous_bal', 1, $invoice_layout->show_previous_bal, ['class' =>
                'input-icheck']); !!} @lang('lang_v1.show_previous_bal_due')</label>
              @show_tooltip(__('lang_v1.previous_bal_due_help'))
            </div>
          </div>
        </div>
        <div class="col-sm-4">
          <div class="form-group">
            {!! Form::label('change_return_label', __('lang_v1.change_return_label') . ':' ) !!}
            @show_tooltip(__('lang_v1.change_return_help'))
            {!! Form::text('change_return_label', $invoice_layout->change_return_label, ['class' =>
            'form-control',
            'placeholder' => __('lang_v1.change_return_label') ]); !!}
          </div>
        </div>
        <div class="col-sm-3 @if($invoice_layout->design != 'slim') hide @endif" id="hide_price_div">
          <div class="form-group">
            <div class="checkbox">
              <label>
                {!! Form::checkbox('common_settings[hide_price]', 1,
                !empty($invoice_layout->common_settings['hide_price']), ['class' => 'input-icheck']); !!}
                @lang('lang_v1.hide_all_prices')</label>
            </div>
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            <label>
              {!! Form::checkbox('common_settings[show_total_in_words]', 1,
              !empty($invoice_layout->common_settings['show_total_in_words']), ['class' => 'input-icheck']); !!}
              @lang('lang_v1.show_total_in_words')</label> @show_tooltip(__('lang_v1.show_in_word_help'))
            @if(!extension_loaded('intl'))
            <p class="help-block">@lang('lang_v1.enable_php_intl_extension')</p>
            @endif
          </div>
        </div>
        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('word_format', __('lang_v1.word_format') . ':') !!}
            @show_tooltip(__('lang_v1.word_format_help'))
            {!! Form::select('common_settings[num_to_word_format]', ['international' =>
            __('lang_v1.international'),
            'indian' => __('lang_v1.indian')], $invoice_layout->common_settings['num_to_word_format'] ??
            'international', ['class' => 'form-control', 'id' => 'word_format']); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('tax_summary_label', __('lang_v1.tax_summary_label') . ':' ) !!}
            {!! Form::text('common_settings[tax_summary_label]',
            !empty($invoice_layout->common_settings['tax_summary_label']) ?
            $invoice_layout->common_settings['tax_summary_label'] : null, ['class' => 'form-control',
            'placeholder' =>
            __('lang_v1.tax_summary_label'), 'id' => 'tax_summary_label' ]); !!}
          </div>
        </div>

      </div>
    </div>
  </div>
  <div class="box box-solid">
    <div class="box-body">
      <div class="row">
        <div class="col-sm-12">

          <div class="col-sm-6 hide">
            <div class="form-group">
              {!! Form::label('highlight_color', __('invoice.highlight_color') . ':' ) !!}
              {!! Form::text('highlight_color', $invoice_layout->highlight_color, ['class' => 'form-control',
              'placeholder' => __('invoice.highlight_color') ]); !!}
            </div>
          </div>

          <div class="clearfix"></div>
          <div class="col-md-12 hide">
            <hr />
          </div>

          <div class="col-sm-12">
            <div class="form-group">
              {!! Form::label('footer_text', __('invoice.footer_text') . ':' ) !!}
              {!! Form::textarea('footer_text', $invoice_layout->footer_text, ['class' => 'form-control',
              'placeholder' => __('invoice.footer_text'), 'rows' => 3]); !!}
            </div>
          </div>
          @if(empty($invoice_layout->is_default))
          <div class="col-sm-6">
            <div class="form-group">
              <br>
              <div class="checkbox">
                <label>
                  {!! Form::checkbox('is_default', 1, $invoice_layout->is_default, ['class' => 'input-icheck']);
                  !!}
                  @lang('barcode.set_as_default')</label>
              </div>
            </div>
          </div>
          @endif

        </div>
      </div>
    </div>
  </div>


  @component('components.widget', ['class' => 'box-solid', 'title' => __('lang_v1.qr_code')])
  <div class="row">
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('show_qr_code', 1, $invoice_layout->show_qr_code, ['class' => 'input-icheck']); !!}
            @lang('lang_v1.show_qr_code')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('common_settings[show_qr_code_label]', 1,
            !empty($invoice_layout->common_settings['show_qr_code_label']), ['class' => 'input-icheck']); !!}
            @lang('lang_v1.show_labels')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('common_settings[zatca_qr]', 1,
            !empty($invoice_layout->common_settings['zatca_qr']),
            ['class' => 'input-icheck', 'id' => 'zatca_qr']); !!} @lang('lang_v1.zatca_qr')</label>
          @show_tooltip(__('lang_v1.zatca_qr_help'))
        </div>
      </div>
    </div>
    <div class="col-sm-4" id="zatca_phase_container" style="display: none;">
      <div class="form-group">
        {!! Form::label('zatca_phase', __('lang_v1.zatca_phase') . ':*') !!}
        {!! Form::select('common_settings[zatca_phase]', [
        'phase_1' => __('lang_v1.zatca_phase1'),
        'phase_2' => __('lang_v1.zatca_phase2'),
        ],$invoice_layout->common_settings['zatca_phase'] ?? null , ['class' => 'form-control', 'id' =>
        'zatca_phase']);
        !!}
        <small id="phase2_message" style="display: none; color: green; font-size: 12px;">
          {{ __('lang_v1.phase2_message') }}
        </small>
      </div>
    </div>
    <div class="clearfix"></div>
    <div class="col-md-12">
      <h4>@lang('lang_v1.fields_to_be_shown'):</h4>
    </div>
    @php
    $qr_code_fields = empty($invoice_layout->qr_code_fields) ? [] : $invoice_layout->qr_code_fields;
    @endphp
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'business_name', in_array('business_name', $qr_code_fields),
            ['class'
            => 'input-icheck']); !!} @lang('business.business_name')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'address', in_array('address', $qr_code_fields), ['class' =>
            'input-icheck']); !!} @lang('lang_v1.business_location_address')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'tax_1', in_array('tax_1', $qr_code_fields), ['class' =>
            'input-icheck']); !!} @lang('lang_v1.business_tax_1')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'tax_2', in_array('tax_2', $qr_code_fields), ['class' =>
            'input-icheck']); !!} @lang('lang_v1.business_tax_2')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'invoice_no', in_array('invoice_no', $qr_code_fields), ['class'
            =>
            'input-icheck']); !!} @lang('sale.invoice_no')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'invoice_datetime', in_array('invoice_datetime',
            $qr_code_fields),
            ['class' => 'input-icheck']); !!} @lang('lang_v1.invoice_datetime')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'subtotal', in_array('subtotal', $qr_code_fields), ['class' =>
            'input-icheck']); !!} @lang('sale.subtotal')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'total_amount', in_array('total_amount', $qr_code_fields),
            ['class'
            => 'input-icheck']); !!} @lang('lang_v1.total_amount_with_tax')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'total_tax', in_array('total_tax', $qr_code_fields), ['class'
            =>
            'input-icheck']); !!} @lang('lang_v1.total_tax')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'customer_name', in_array('customer_name', $qr_code_fields),
            ['class'
            => 'input-icheck']); !!} @lang('sale.customer_name')</label>
        </div>
      </div>
    </div>
    <div class="col-sm-4">
      <div class="form-group">
        <div class="checkbox">
          <label>
            {!! Form::checkbox('qr_code_fields[]', 'invoice_url', in_array('invoice_url', $qr_code_fields),
            ['class' =>
            'input-icheck']); !!} @lang('lang_v1.view_invoice_url')</label>
        </div>
      </div>
    </div>

  </div>
  @endcomponent
  @if(!empty($enabled_modules) && in_array('types_of_service', $enabled_modules) )
  @include('types_of_service.invoice_layout_settings', ['module_info' => $invoice_layout->module_info])
  @endif
  <!-- Call restaurant module if defined -->
  @include('restaurant.partials.invoice_layout', ['module_info' => $invoice_layout->module_info, 'edit_il' =>
  true])

  @if(Module::has('Repair'))
  @include('repair::layouts.partials.invoice_layout_settings', ['module_info' => $invoice_layout->module_info,
  'edit_il'
  => true])
  @endif


  <div class="box box-solid">
    <div class="box-header with-border">
      <h3 class="box-title">@lang('lang_v1.layout_credit_note')</h3>
    </div>

    <div class="box-body">
      <div class="row">

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cn_heading', __('lang_v1.cn_heading') . ':' ) !!}
            {!! Form::text('cn_heading', $invoice_layout->cn_heading, ['class' => 'form-control', 'placeholder' =>
            __('lang_v1.cn_heading') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cn_no_label', __('lang_v1.cn_no_label') . ':' ) !!}
            {!! Form::text('cn_no_label', $invoice_layout->cn_no_label, ['class' => 'form-control', 'placeholder'
            =>
            __('lang_v1.cn_no_label') ]); !!}
          </div>
        </div>

        <div class="col-sm-3">
          <div class="form-group">
            {!! Form::label('cn_amount_label', __('lang_v1.cn_amount_label') . ':' ) !!}
            {!! Form::text('cn_amount_label', $invoice_layout->cn_amount_label, ['class' => 'form-control',
            'placeholder' => __('lang_v1.cn_amount_label') ]); !!}
          </div>
        </div>

      </div>
    </div>
  </div>

  <div class="row">
    <div class="col-sm-12 text-center">
      <button type="submit"
        class="tw-dw-btn tw-dw-btn-primary tw-text-white tw-dw-btn-lg">@lang('messages.update')</button>
    </div>
  </div>

  {!! Form::close() !!}
</section>
<!-- /.content -->
@stop
@section('javascript')
<script type="text/javascript">
  __page_leave_confirmation('#add_invoice_layout_form');
    $(document).on('ifChanged', '#show_letter_head', function() {
        letter_head_changed();
    });

    function letter_head_changed() {
        if($('#show_letter_head').is(":checked")) {
            $('.hide-for-letterhead').addClass('hide');
            $('.letter_head_input').removeClass('hide');
        } else {
            $('.hide-for-letterhead').removeClass('hide');
            $('.letter_head_input').addClass('hide');
        }
    }

    $(document).ready(function(){
        letter_head_changed();
    })
</script>
<script>
  $(document).ready(function () {
      function toggleZatcaPhase() {
          if ($('#zatca_qr').is(':checked')) {
              $('#zatca_phase_container').fadeIn();
          } else {
              $('#zatca_phase_container').fadeOut();
          }
      }

      function checkPhaseSelection(){
        if ($('#zatca_phase').val() === 'phase_2') {
            $('#phase2_message').fadeIn();
        } else {
            $('#phase2_message').fadeOut();
        }
      }
      // Initial check on page load
      toggleZatcaPhase();
      checkPhaseSelection();

      $('#zatca_qr').on('ifChanged', function(event){
        //Check if checkbox is checked or not
        toggleZatcaPhase()
      });

      $('#zatca_phase').on('change', function () {
        checkPhaseSelection();
      });
  });
</script>
@endsection

Step 6: Update Receipt Details Method

Modify getReceiptDetails Method

Update the app/Utils/TransactionUtil.php: getReceiptDetails method to include watermark data:

    public function getReceiptDetails($transaction_id, $location_id, $invoice_layout, $business_details, $location_details, $receipt_printer_type)
    {
        $il = $invoice_layout;

        $transaction = Transaction::find($transaction_id);
        $transaction_type = $transaction->type;

        $output = [
            'header_text' => isset($il->header_text) ? $il->header_text : '',
            'business_name' => ($il->show_business_name == 1) ? $business_details->name : '',
            'location_name' => ($il->show_location_name == 1) ? $location_details->name : '',
            'sub_heading_line1' => trim($il->sub_heading_line1),
            'sub_heading_line2' => trim($il->sub_heading_line2),
            'sub_heading_line3' => trim($il->sub_heading_line3),
            'sub_heading_line4' => trim($il->sub_heading_line4),
            'sub_heading_line5' => trim($il->sub_heading_line5),
            'table_product_label' => $il->table_product_label,
            'table_qty_label' => $il->table_qty_label,
            'table_unit_price_label' => $il->table_unit_price_label,
            'table_subtotal_label' => $il->table_subtotal_label,
        ];

        //Display name
        $output['display_name'] = $output['business_name'];
        if (! empty($output['location_name'])) {
            if (! empty($output['display_name'])) {
                $output['display_name'] .= ', ';
            }
            $output['display_name'] .= $output['location_name'];
        }

        //Codes
        if (! empty($business_details->code_label_1) && ! empty($business_details->code_1)) {
            $output['code_label_1'] = $business_details->code_label_1;
            $output['code_1'] = $business_details->code_1;
        }

        if (! empty($business_details->code_label_1) && ! empty($business_details->code_1)) {
            $output['code_label_2'] = $business_details->code_label_2;
            $output['code_2'] = $business_details->code_2;
        }

        if ($il->show_letter_head == 1) {
            $output['letter_head'] = ! empty($il->letter_head) &&
                file_exists(public_path('uploads/invoice_logos/' . $il->letter_head)) ?
                asset('uploads/invoice_logos/' . $il->letter_head) : null;
        }

        //Logo
        $output['logo'] = $il->show_logo != 0 && ! empty($il->logo) && file_exists(public_path('uploads/invoice_logos/' . $il->logo)) ? asset('uploads/invoice_logos/' . $il->logo) : false;
        //Watermark
        $output['watermark_logo'] = null;
        $output['show_watermark'] = false;
        $output['watermark_width'] = 300;
        $output['watermark_height'] = 300;
        $output['watermark_opacity'] = '0.1';
        $output['watermark_position'] = 'center';

        if ($il->show_watermark == 1 && !empty($il->watermark_logo) && file_exists(public_path('uploads/invoice_logos/' . $il->watermark_logo))) {
            $output['watermark_logo'] = $il->watermark_logo;
            $output['show_watermark'] = true;
            $output['watermark_width'] = $il->watermark_width ?? 300;
            $output['watermark_height'] = $il->watermark_height ?? 300;
            $output['watermark_opacity'] = $il->watermark_opacity ?? '0.1';
            $output['watermark_position'] = $il->watermark_position ?? 'center';
        }
        //Address
        $output['address'] = '';
        $temp = [];
        if ($il->show_landmark == 1) {
            $temp[] = $location_details->landmark;
        }
        if ($il->show_city == 1 && ! empty($location_details->city)) {
            $temp[] = $location_details->city;
        }
        if ($il->show_state == 1 && ! empty($location_details->state)) {
            $temp[] = $location_details->state;
        }
        if ($il->show_zip_code == 1 && ! empty($location_details->zip_code)) {
            $temp[] = $location_details->zip_code;
        }
        if ($il->show_country == 1 && ! empty($location_details->country)) {
            $temp[] = $location_details->country;
        }
        if (! empty($temp)) {
            $output['address'] .= implode(', ', $temp);
        }

        $output['website'] = $location_details->website;
        $output['location_custom_fields'] = '';
        $temp = [];
        $location_custom_field_settings = ! empty($il->location_custom_fields) ? $il->location_custom_fields : [];
        if (! empty($location_details->custom_field1) && in_array('custom_field1', $location_custom_field_settings)) {
            $temp[] = $location_details->custom_field1;
        }
        if (! empty($location_details->custom_field2) && in_array('custom_field2', $location_custom_field_settings)) {
            $temp[] = $location_details->custom_field2;
        }
        if (! empty($location_details->custom_field3) && in_array('custom_field3', $location_custom_field_settings)) {
            $temp[] = $location_details->custom_field3;
        }
        if (! empty($location_details->custom_field4) && in_array('custom_field4', $location_custom_field_settings)) {
            $temp[] = $location_details->custom_field4;
        }
        if (! empty($temp)) {
            $output['location_custom_fields'] .= implode(', ', $temp);
        }

        //Tax Info
        if ($il->show_tax_1 == 1 && ! empty($business_details->tax_number_1)) {
            $output['tax_label1'] = ! empty($business_details->tax_label_1) ? $business_details->tax_label_1 . ': ' : '';

            $output['tax_info1'] = $business_details->tax_number_1;
        }
        if ($il->show_tax_2 == 1 && ! empty($business_details->tax_number_2)) {
            if (! empty($output['tax_info1'])) {
                $output['tax_info1'] .= ', ';
            }

            $output['tax_label2'] = ! empty($business_details->tax_label_2) ? $business_details->tax_label_2 . ': ' : '';

            $output['tax_info2'] = $business_details->tax_number_2;
        }

        //Shop Contact Info
        $output['contact'] = '';
        if ($il->show_mobile_number == 1 && ! empty($location_details->mobile)) {
            $output['contact'] .= '<b>' . __('contact.mobile') . ':</b> ' . $location_details->mobile;
        }
        if ($il->show_alternate_number == 1 && ! empty($location_details->alternate_number)) {
            if (empty($output['contact'])) {
                $output['contact'] .= __('contact.mobile') . ': ' . $location_details->alternate_number;
            } else {
                $output['contact'] .= ', ' . $location_details->alternate_number;
            }
        }
        if ($il->show_email == 1 && ! empty($location_details->email)) {
            if (! empty($output['contact'])) {
                $output['contact'] .= "\n";
            }
            $output['contact'] .= '<br>' . __('business.email') . ': ' . $location_details->email;
        }

        //Customer show_customer
        $customer = Contact::find($transaction->contact_id);

        $output['customer_info'] = '';
        $output['customer_tax_number'] = '';
        $output['customer_tax_label'] = '';
        $output['customer_custom_fields'] = '';
        if ($il->show_customer == 1) {
            $output['customer_label'] = ! empty($il->customer_label) ? $il->customer_label : '';
            $output['customer_name'] = ! empty($customer->name) ? $customer->name : $customer->supplier_business_name;
            $output['customer_mobile'] = $customer->mobile;

            if ($receipt_printer_type != 'printer') {
                $output['customer_info'] .= $customer->contact_address;
                if (! empty($customer->contact_address)) {
                    $output['customer_info'] .= '<br>';
                }
                $output['customer_info'] .= '<b>' . __('contact.mobile') . '</b>: ' . $customer->mobile;
                if (! empty($customer->landline)) {
                    $output['customer_info'] .= ', ' . $customer->landline;
                }
            }

            $output['customer_tax_number'] = $customer->tax_number;
            $output['customer_tax_label'] = ! empty($il->client_tax_label) ? $il->client_tax_label : '';

            $temp = [];
            $customer_custom_fields_settings = ! empty($il->contact_custom_fields) ? $il->contact_custom_fields : [];
            $contact_custom_labels = $this->getCustomLabels($business_details, 'contact');
            if (! empty($customer->custom_field1) && in_array('custom_field1', $customer_custom_fields_settings)) {
                if (! empty($contact_custom_labels['custom_field_1'])) {
                    $temp[] = $contact_custom_labels['custom_field_1'] . ': ' . $customer->custom_field1;
                } else {
                    $temp[] = $customer->custom_field1;
                }
            }
            if (! empty($customer->custom_field2) && in_array('custom_field2', $customer_custom_fields_settings)) {
                if (! empty($contact_custom_labels['custom_field_2'])) {
                    $temp[] = $contact_custom_labels['custom_field_2'] . ': ' . $customer->custom_field2;
                } else {
                    $temp[] = $customer->custom_field2;
                }
            }
            if (! empty($customer->custom_field3) && in_array('custom_field3', $customer_custom_fields_settings)) {
                if (! empty($contact_custom_labels['custom_field_3'])) {
                    $temp[] = $contact_custom_labels['custom_field_3'] . ': ' . $customer->custom_field3;
                } else {
                    $temp[] = $customer->custom_field3;
                }
            }
            if (! empty($customer->custom_field4) && in_array('custom_field4', $customer_custom_fields_settings)) {
                if (! empty($contact_custom_labels['custom_field_4'])) {
                    $temp[] = $contact_custom_labels['custom_field_4'] . ': ' . $customer->custom_field4;
                } else {
                    $temp[] = $customer->custom_field1;
                }
            }
            if (! empty($temp)) {
                $output['customer_custom_fields'] .= implode('<br>', $temp);
            }

            //To be used in pdfs
            $customer_address = [];
            if (! empty($customer->supplier_business_name)) {
                $customer_address[] = $customer->supplier_business_name;
            }
            if (! empty($customer->address_line_1)) {
                $customer_address[] = '<br>' . $customer->address_line_1;
            }
            if (! empty($customer->address_line_2)) {
                $customer_address[] = '<br>' . $customer->address_line_2;
            }
            if (! empty($customer->city)) {
                $customer_address[] = '<br>' . $customer->city;
            }
            if (! empty($customer->state)) {
                $customer_address[] = $customer->state;
            }
            if (! empty($customer->country)) {
                $customer_address[] = $customer->country;
            }
            if (! empty($customer->zip_code)) {
                $customer_address[] = '<br>' . $customer->zip_code;
            }
            if (! empty(trim($customer->name))) {
                $customer_address[] = '<br>' . $customer->name;
            }
            if (! empty($customer->mobile)) {
                $customer_address[] = '<br>' . $customer->mobile;
            }
            if (! empty($customer->landline)) {
                $customer_address[] = $customer->landline;
            }

            $output['customer_info_address'] = '';
            if (! empty($customer_address)) {
                $output['customer_info_address'] = implode(', ', $customer_address);
            }
        }

        if ($il->show_reward_point == 1) {
            $output['customer_rp_label'] = $business_details->rp_name;
            $output['customer_total_rp'] = $customer->total_rp;
        }

        $output['client_id'] = '';
        $output['client_id_label'] = '';
        if ($il->show_client_id == 1) {
            $output['client_id_label'] = ! empty($il->client_id_label) ? $il->client_id_label : '';
            $output['client_id'] = ! empty($customer->contact_id) ? $customer->contact_id : '';
        }

        //Sales person info
        $output['sales_person'] = '';
        $output['sales_person_label'] = '';
        if ($il->show_sales_person == 1) {
            $output['sales_person_label'] = ! empty($il->sales_person_label) ? $il->sales_person_label : '';
            $output['sales_person'] = ! empty($transaction->sales_person->user_full_name) ? $transaction->sales_person->user_full_name : '';
        }

        //commission agent info
        $output['commission_agent'] = '';
        $output['commission_agent_label'] = '';
        if ($il->show_commission_agent == 1) {
            $output['commission_agent_label'] = ! empty($il->commission_agent_label) ? $il->commission_agent_label : '';
            $output['commission_agent'] = ! empty($transaction->sale_commission_agent->user_full_name) ? $transaction->sale_commission_agent->user_full_name : '';
        }

        //Invoice info
        $output['invoice_no'] = $transaction->invoice_no;
        $output['invoice_no_prefix'] = $il->invoice_no_prefix;
        $output['shipping_address'] = ! empty($transaction->shipping_address()) ? $transaction->shipping_address() : $transaction->shipping_address;

        //Heading & invoice label, when quotation use the quotation heading.
        if ($transaction_type == 'sell_return') {
            $output['invoice_heading'] = $il->cn_heading;
            $output['invoice_no_prefix'] = $il->cn_no_label;

            //Parent sell details(return_parent_id)
            $output['parent_invoice_no'] = Transaction::find($transaction->return_parent_id)->invoice_no;
            $output['parent_invoice_no_prefix'] = $il->invoice_no_prefix;
        } elseif ($transaction->status == 'draft' && $transaction->sub_status == 'proforma' && ! empty($il->common_settings['proforma_heading'])) {
            $output['invoice_heading'] = $il->common_settings['proforma_heading'];
        } elseif ($transaction->status == 'draft' && $transaction->is_quotation == 1) {
            $output['invoice_heading'] = $il->quotation_heading;
            $output['invoice_no_prefix'] = $il->quotation_no_prefix;
        } elseif ($transaction_type == 'sales_order') {
            $output['invoice_heading'] = ! empty($il->common_settings['sales_order_heading']) ? $il->common_settings['sales_order_heading'] : __('lang_v1.sales_order');
            $output['invoice_no_prefix'] = $il->quotation_no_prefix;
        } else {
            $output['invoice_heading'] = $il->invoice_heading;
            if ($transaction->payment_status == 'paid' && ! empty($il->invoice_heading_paid)) {
                $output['invoice_heading'] .= ' ' . $il->invoice_heading_paid;
            } elseif (in_array($transaction->payment_status, ['due', 'partial']) && ! empty($il->invoice_heading_not_paid)) {
                $output['invoice_heading'] .= ' ' . $il->invoice_heading_not_paid;
            }
        }

        $output['date_label'] = $il->date_label;
        if (blank($il->date_time_format)) {
            $output['invoice_date'] = $this->format_date($transaction->transaction_date, true, $business_details);
        } else {
            $output['invoice_date'] = \Carbon::createFromFormat('Y-m-d H:i:s', $transaction->transaction_date)->format($il->date_time_format);
        }

        $output['transaction_date'] = $transaction->transaction_date;
        $output['date_time_format'] = $business_details->date_format;
        $output['currency_symbol'] = $business_details->currency_symbol;

        $output['hide_price'] = ! empty($il->common_settings['hide_price']) ? true : false;

        if (! empty($il->common_settings['show_due_date']) && $transaction->payment_status != 'paid') {
            $output['due_date_label'] = ! empty($il->common_settings['due_date_label']) ? $il->common_settings['due_date_label'] : '';
            $due_date = $transaction->due_date;
            if (! empty($due_date)) {
                if (blank($il->date_time_format)) {
                    $output['due_date'] = $this->format_date($due_date->toDateTimeString(), true, $business_details);
                } else {
                    $output['due_date'] = \Carbon::createFromFormat('Y-m-d H:i:s', $due_date->toDateTimeString())->format($il->date_time_format);
                }
            }
        }

        $show_currency = true;
        if ($receipt_printer_type == 'printer' && trim($business_details->currency_symbol) != '$') {
            $show_currency = false;
        }

        //Invoice product lines
        $is_lot_number_enabled = $business_details->enable_lot_number;
        $is_product_expiry_enabled = $business_details->enable_product_expiry;

        $output['lines'] = [];
        $total_exempt = 0;
        if (in_array($transaction_type, ['sell', 'sales_order'])) {
            $sell_line_relations = ['modifiers', 'sub_unit', 'warranties'];

            if ($is_lot_number_enabled == 1) {
                $sell_line_relations[] = 'lot_details';
            }

            $lines = $transaction->sell_lines()->whereNull('parent_sell_line_id')->with($sell_line_relations)->get();

            foreach ($lines as $key => $value) {
                if (! empty($value->sub_unit_id)) {
                    $formated_sell_line = $this->recalculateSellLineTotals($business_details->id, $value);

                    $lines[$key] = $formated_sell_line;
                }
            }

            $output['item_discount_label'] = $il->common_settings['item_discount_label'] ?? '';

            $output['discounted_unit_price_label'] = $il->common_settings['discounted_unit_price_label'] ?? '';

            $output['show_base_unit_details'] = ! empty($il->common_settings['show_base_unit_details']);

            $output['tax_summary_label'] = $il->common_settings['tax_summary_label'] ?? '';
            $details = $this->_receiptDetailsSellLines($lines, $il, $business_details);

            $output['lines'] = $details['lines'];
            $output['taxes'] = [];
            $total_quantity = 0;
            $total_line_discount = 0;
            $total_line_taxes = 0;
            $subtotal_exc_tax = 0;
            $unique_items = [];
            foreach ($details['lines'] as $line) {
                if (! empty($line['group_tax_details'])) {
                    foreach ($line['group_tax_details'] as $tax_group_detail) {
                        if (! isset($output['taxes'][$tax_group_detail['name']])) {
                            $output['taxes'][$tax_group_detail['name']] = 0;
                        }
                        $output['taxes'][$tax_group_detail['name']] += $tax_group_detail['calculated_tax'];
                    }
                } elseif (! empty($line['tax_id'])) {
                    if (! isset($output['taxes'][$line['tax_name']])) {
                        $output['taxes'][$line['tax_name']] = 0;
                    }

                    $output['taxes'][$line['tax_name']] += ($line['tax_unformatted'] * $line['quantity_uf']);
                }

                if (! empty($line['tax_id']) && $line['tax_percent'] == 0) {
                    $total_exempt += $line['line_total_uf'];
                }
                $subtotal_exc_tax += $line['line_total_exc_tax_uf'];
                $total_quantity += $line['quantity_uf'];
                $total_line_discount += ($line['line_discount_uf'] * $line['quantity_uf']);
                $total_line_taxes += ($line['tax_unformatted'] * $line['quantity_uf']);
                if (! empty($line['variation_id']) && ! in_array($line['variation_id'], $unique_items)) {
                    $unique_items[] = $line['variation_id'];
                }
            }

            if (! empty($il->common_settings['total_quantity_label'])) {
                $output['total_quantity_label'] = $il->common_settings['total_quantity_label'];
                $output['total_quantity'] = $this->num_f($total_quantity, false, $business_details, true);
            }

            if (! empty($il->common_settings['total_items_label'])) {
                $output['total_items_label'] = $il->common_settings['total_items_label'];
                $output['total_items'] = count($unique_items);
            }

            $output['subtotal_exc_tax'] = $this->num_f($subtotal_exc_tax, true, $business_details);
            $output['total_line_discount'] = ! empty($total_line_discount) ? $this->num_f($total_line_discount, true, $business_details) : 0;
        } elseif ($transaction_type == 'sell_return') {
            $parent_sell = Transaction::find($transaction->return_parent_id);
            $lines = $parent_sell->sell_lines;
            $total_line_taxes = 0;
            foreach ($lines as $key => $value) {
                if (! empty($value->sub_unit_id)) {
                    $formated_sell_line = $this->recalculateSellLineTotals($business_details->id, $value);

                    $lines[$key] = $formated_sell_line;
                }
            }

            $details = $this->_receiptDetailsSellReturnLines($lines, $il, $business_details);
            $output['lines'] = $details['lines'];

            $output['taxes'] = [];
            foreach ($details['lines'] as $line) {
                if (! empty($line['group_tax_details'])) {
                    foreach ($line['group_tax_details'] as $tax_group_detail) {
                        if (! isset($output['taxes'][$tax_group_detail['name']])) {
                            $output['taxes'][$tax_group_detail['name']] = 0;
                        }
                        $output['taxes'][$tax_group_detail['name']] += $tax_group_detail['calculated_tax'];
                    }
                }

                $total_line_taxes += ($line['tax_unformatted'] * $line['quantity']);
            }
        }

        //show cat code
        $output['show_cat_code'] = $il->show_cat_code;
        $output['cat_code_label'] = $il->cat_code_label;

        //Subtotal
        $output['subtotal_label'] = $il->sub_total_label . ':';
        $output['subtotal'] = ($transaction->total_before_tax != 0) ? $this->num_f($transaction->total_before_tax, $show_currency, $business_details) : 0;
        $output['subtotal_unformatted'] = ($transaction->total_before_tax != 0) ? $transaction->total_before_tax : 0;

        //round off
        $output['round_off_label'] = ! empty($il->round_off_label) ? $il->round_off_label . ':' : __('lang_v1.round_off') . ':';
        $output['round_off'] = $this->num_f($transaction->round_off_amount, $show_currency, $business_details);
        $output['round_off_amount'] = $transaction->round_off_amount;
        $output['total_exempt'] = $this->num_f($total_exempt, $show_currency, $business_details);
        $output['total_exempt_uf'] = $total_exempt;

        $taxed_subtotal = $output['subtotal_unformatted'] - $total_exempt;
        $output['taxed_subtotal'] = $this->num_f($taxed_subtotal, $show_currency, $business_details);

        //Discount
        $discount_amount = $this->num_f($transaction->discount_amount, $show_currency, $business_details);
        $output['line_discount_label'] = $invoice_layout->discount_label;
        $output['discount_label'] = $invoice_layout->discount_label;
        $output['discount_label'] .= ($transaction->discount_type == 'percentage') ? ' <small>(' . $this->num_f($transaction->discount_amount, false, $business_details) . '%)</small> :' : '';

        if ($transaction->discount_type == 'percentage') {
            $discount = ($transaction->discount_amount / 100) * $transaction->total_before_tax;
        } else {
            $discount = $transaction->discount_amount;
        }
        $output['discount'] = ($discount != 0) ? $this->num_f($discount, $show_currency, $business_details) : 0;

        //reward points
        if ($business_details->enable_rp == 1 && ! empty($transaction->rp_redeemed)) {
            $output['reward_point_label'] = $business_details->rp_name;
            $output['reward_point_amount'] = $this->num_f($transaction->rp_redeemed_amount, $show_currency, $business_details);
        }

        //Format tax
        if (! empty($output['taxes'])) {
            $total_tax = 0;
            foreach ($output['taxes'] as $key => $value) {
                $total_tax += $value;

                $output['taxes'][$key] = $this->num_f($value, $show_currency, $business_details);
            }

            $output['taxes'][trans('lang_v1.total_tax')] = $this->num_f($total_tax, $show_currency, $business_details);
        }

        //Order Tax
        $tax = $transaction->tax;
        $output['tax_label'] = $invoice_layout->tax_label;
        $output['line_tax_label'] = $invoice_layout->tax_label;
        if (! empty($tax) && ! empty($tax->name)) {
            $output['tax_label'] .= ' (' . $tax->name . ')';
        }
        $output['tax_label'] .= ':';
        $output['tax'] = ($transaction->tax_amount != 0) ? $this->num_f($transaction->tax_amount, $show_currency, $business_details) : 0;

        if ($transaction->tax_amount != 0 && $tax->is_tax_group) {
            $transaction_group_tax_details = $this->groupTaxDetails($tax, $transaction->tax_amount);

            $output['group_tax_details'] = [];
            foreach ($transaction_group_tax_details as $value) {
                $output['group_tax_details'][$value['name']] = $this->num_f($value['calculated_tax'], $show_currency, $business_details);
            }
        }

        //Shipping charges
        $output['shipping_charges'] = ($transaction->shipping_charges != 0) ? $this->num_f($transaction->shipping_charges, $show_currency, $business_details) : 0;
        $output['shipping_charges_label'] = trans('sale.shipping_charges');
        //Shipping details
        $output['shipping_details'] = $transaction->shipping_details;
        $output['delivered_to'] = $transaction->delivered_to;
        $output['shipping_details_label'] = trans('sale.shipping_details');
        $output['packing_charge_label'] = trans('lang_v1.packing_charge');
        $output['packing_charge'] = ($transaction->packing_charge != 0) ? $this->num_f($transaction->packing_charge, $show_currency, $business_details) : 0;

        //Total
        if ($transaction_type == 'sell_return') {
            $output['total_label'] = $invoice_layout->cn_amount_label . ':';
            $output['total'] = $this->num_f($transaction->final_total, $show_currency, $business_details);
        } else {
            $output['total_label'] = $invoice_layout->total_label . ':';
            $output['total'] = $this->num_f($transaction->final_total, $show_currency, $business_details);
        }
        if (! empty($il->common_settings['show_total_in_words'])) {
            $word_format = isset($il->common_settings['num_to_word_format']) ? $il->common_settings['num_to_word_format'] : 'international';
            $output['total_in_words'] = $this->numToWord($transaction->final_total, null, $word_format);
        }

        $output['total_unformatted'] = $transaction->final_total;

        //Paid & Amount due, only if final
        if ($transaction_type == 'sell' && $transaction->status == 'final') {
            $paid_amount = $this->getTotalPaid($transaction->id);
            $due = $transaction->final_total - $paid_amount;

            $output['total_paid'] = ($paid_amount == 0) ? 0 : $this->num_f($paid_amount, $show_currency, $business_details);
            $output['total_paid_label'] = $il->paid_label;
            $output['total_due'] = ($due == 0) ? 0 : $this->num_f($due, $show_currency, $business_details);
            $output['total_due_label'] = $il->total_due_label;

            if ($il->show_previous_bal == 1) {
                $all_due = $this->getContactDue($transaction->contact_id);
                if (! empty($all_due)) {
                    $output['all_bal_label'] = $il->prev_bal_label;
                    $output['all_due'] = $this->num_f($all_due, $show_currency, $business_details);
                }
            }

            //Get payment details
            $output['payments'] = [];
            if ($il->show_payments == 1) {
                $payments = $transaction->payment_lines->toArray();
                $payment_types = $this->payment_types($transaction->location_id, true);
                if (! empty($payments)) {
                    foreach ($payments as $value) {
                        $method = ! empty($payment_types[$value['method']]) ? $payment_types[$value['method']] : '';
                        if ($value['method'] == 'cash') {
                            $output['payments'][] =
                                [
                                    'method' => $method . ($value['is_return'] == 1 ? ' (' . $il->change_return_label . ')(-)' : ''),
                                    'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                    'date' => $this->format_date($value['paid_on'], false, $business_details),
                                ];
                            if ($value['is_return'] == 1) {
                            }
                        } elseif ($value['method'] == 'card') {
                            $output['payments'][] =
                                [
                                    'method' => $method . (! empty($value['card_transaction_number']) ? (', Transaction Number:' . $value['card_transaction_number']) : ''),
                                    'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                    'date' => $this->format_date($value['paid_on'], false, $business_details),
                                ];
                        } elseif ($value['method'] == 'cheque') {
                            $output['payments'][] =
                                [
                                    'method' => $method . (! empty($value['cheque_number']) ? (', Cheque Number:' . $value['cheque_number']) : ''),
                                    'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                    'date' => $this->format_date($value['paid_on'], false, $business_details),
                                ];
                        } elseif ($value['method'] == 'bank_transfer') {
                            $output['payments'][] =
                                [
                                    'method' => $method . (! empty($value['bank_account_number']) ? (', Account Number:' . $value['bank_account_number']) : ''),
                                    'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                    'date' => $this->format_date($value['paid_on'], false, $business_details),
                                ];
                        } elseif ($value['method'] == 'advance') {
                            $output['payments'][] =
                                [
                                    'method' => $method,
                                    'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                    'date' => $this->format_date($value['paid_on'], false, $business_details),
                                ];
                        } elseif ($value['method'] == 'other') {
                            $output['payments'][] =
                                [
                                    'method' => $method,
                                    'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                    'date' => $this->format_date($value['paid_on'], false, $business_details),
                                ];
                        }

                        for ($i = 1; $i < 8; $i++) {
                            if ($value['method'] == "custom_pay_{$i}") {
                                $output['payments'][] =
                                    [
                                        'method' => $method . (! empty($value['transaction_no']) ? (', ' . trans('lang_v1.transaction_no') . ':' . $value['transaction_no']) : ''),
                                        'amount' => $this->num_f($value['amount'], $show_currency, $business_details),
                                        'date' => $this->format_date($value['paid_on'], false, $business_details),
                                    ];
                            }
                        }
                    }
                }
            }
        }

        $output['additional_expenses'] = [];

        if (! empty($transaction->additional_expense_value_1) && ! empty($transaction->additional_expense_key_1)) {
            $output['additional_expenses'][$transaction->additional_expense_key_1] = $this->num_f($transaction->additional_expense_value_1, $show_currency, $business_details);
        }
        if (! empty($transaction->additional_expense_value_2) && ! empty($transaction->additional_expense_key_2)) {
            $output['additional_expenses'][$transaction->additional_expense_key_2] = $this->num_f($transaction->additional_expense_value_2, $show_currency, $business_details);
        }
        if (! empty($transaction->additional_expense_value_3) && ! empty($transaction->additional_expense_key_3)) {
            $output['additional_expenses'][$transaction->additional_expense_key_3] = $this->num_f($transaction->additional_expense_value_3, $show_currency, $business_details);
        }
        if (! empty($transaction->additional_expense_value_4) && ! empty($transaction->additional_expense_key_4)) {
            $output['additional_expenses'][$transaction->additional_expense_key_4] = $this->num_f($transaction->additional_expense_value_4, $show_currency, $business_details);
        }

        //Check for barcode
        $output['barcode'] = ($il->show_barcode == 1) ? $transaction->invoice_no : false;

        //Additional notes
        $output['additional_notes'] = $transaction->additional_notes;
        $output['footer_text'] = $invoice_layout->footer_text;

        //Barcode related information.
        $output['show_barcode'] = ! empty($il->show_barcode) ? true : false;

        if (in_array($transaction_type, ['sell', 'sales_order'])) {
            //Qr code related information.
            $output['show_qr_code'] = ! empty($il->show_qr_code) ? true : false;

            $zatca_qr = ! empty($il->common_settings['zatca_qr']) ? true : false;

            if ($zatca_qr) {
                $total_order_tax = $transaction->tax_amount + $total_line_taxes;

                $zatca_phase = ! empty($il->common_settings['zatca_phase']) ? $il->common_settings['zatca_phase'] : '';
                $qr_code_text = $this->_zatca_qr_text($business_details->name, $business_details->tax_number_1, $transaction, $total_order_tax, $zatca_phase);
                // $qr_code_text = $this->_zatca_qr_text( $transaction);
            } else {
                $is_label_enabled = ! empty($il->common_settings['show_qr_code_label']) ? true : false;
                $qr_code_details = [];
                $qr_code_fields = ! empty($il->qr_code_fields) ? $il->qr_code_fields : [];

                if (in_array('business_name', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? __('business.business') . ': ' . $business_details->name : $business_details->name;
                }
                if (in_array('address', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? __('business.address') . ': ' . $location_details->name . ', ' . $output['address'] : $location_details->name . ' ' . str_replace(',', '', $output['address']);
                }
                if (in_array('tax_1', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? $business_details->tax_label_1 . ': ' . $business_details->tax_number_1 : $business_details->tax_number_1;
                }
                if (in_array('tax_2', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? $business_details->tax_label_2 . ' ' . $business_details->tax_number_2 : $business_details->tax_number_2;
                }
                if (in_array('invoice_no', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? $il->invoice_no_prefix . ': ' . $transaction->invoice_no : $transaction->invoice_no;
                }
                if (in_array('invoice_datetime', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? $output['date_label'] . ': ' . $output['invoice_date'] : $output['invoice_date'];
                }
                if (in_array('subtotal', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? $output['subtotal_label'] . ' ' . $output['subtotal'] : $output['subtotal'];
                }
                if (in_array('total_amount', $qr_code_fields)) {
                    $qr_code_details[] = $is_label_enabled ? $output['total_label'] . ' ' . $output['total'] : $output['total'];
                }
                if (in_array('total_tax', $qr_code_fields)) {
                    $total_order_tax = $transaction->tax_amount + $total_line_taxes;
                    $total_order_tax_formatted = $this->num_f($total_order_tax, $show_currency, $business_details);
                    $qr_code_details[] = $is_label_enabled ? __('sale.tax') . ': ' . $total_order_tax_formatted : $total_order_tax_formatted;
                }
                if (in_array('customer_name', $qr_code_fields)) {
                    $cust_label = $il->customer_label ?? __('contact.customer');
                    $qr_code_details[] = $is_label_enabled ? $cust_label . ': ' . $customer->full_name : $customer->full_name;
                }
                if (in_array('invoice_url', $qr_code_fields)) {
                    $qr_code_details[] = $this->getInvoiceUrl($transaction->id, $business_details->id);
                }

                $output['qr_code_details'] = $qr_code_details;

                $qr_code_text = $is_label_enabled ? implode(', ', $qr_code_details) : implode(' ', $qr_code_details);
            }

            if ($transaction->status == 'final') {
                $output['qr_code_text'] = $qr_code_text;
            }
            // add this seprate for sell retuen qr text of zatca
        } else if (in_array($transaction_type, ['sell_return'])) {

            $output['show_qr_code'] = ! empty($il->show_qr_code) ? true : false;
            $zatca_qr = ! empty($il->common_settings['zatca_qr']) ? true : false;
            if ($zatca_qr) {
                $total_order_tax = $transaction->tax_amount + $total_line_taxes;
                $zatca_phase = ! empty($il->common_settings['zatca_phase']) ? $il->common_settings['zatca_phase'] : '';
                $qr_code_text = $this->_zatca_qr_text($business_details->name, $business_details->tax_number_1, $transaction, $total_order_tax, $zatca_phase);
            }

            if ($transaction->status == 'final') {
                $output['qr_code_text'] = $qr_code_text;
            }
        }
        //Module related information.
        $il->module_info = ! empty($il->module_info) ? json_decode($il->module_info, true) : [];
        if (! empty($il->module_info['tables']) && $this->isModuleEnabled('tables')) {
            //Table label & info
            $output['table_label'] = null;
            $output['table'] = null;
            if (isset($il->module_info['tables']['show_table'])) {
                $output['table_label'] = ! empty($il->module_info['tables']['table_label']) ? $il->module_info['tables']['table_label'] : '';
                if (! empty($transaction->res_table_id)) {
                    $table = ResTable::find($transaction->res_table_id);
                }

                //res_table_id
                $output['table'] = ! empty($table->name) ? $table->name : '';
            }
        }

        if (! empty($il->module_info['types_of_service']) && $this->isModuleEnabled('types_of_service') && ! empty($transaction->types_of_service_id)) {
            //Table label & info
            $output['types_of_service_label'] = null;
            $output['types_of_service'] = null;
            if (isset($il->module_info['types_of_service']['show_types_of_service'])) {
                $output['types_of_service_label'] = ! empty($il->module_info['types_of_service']['types_of_service_label']) ? $il->module_info['types_of_service']['types_of_service_label'] : '';
                $output['types_of_service'] = $transaction->types_of_service->name;
            }

            if (isset($il->module_info['types_of_service']['show_tos_custom_fields'])) {
                $types_of_service_custom_labels = $this->getCustomLabels($business_details, 'types_of_service');
                $output['types_of_service_custom_fields'] = [];
                if (! empty($transaction->service_custom_field_1)) {
                    $tos_custom_label_1 = $types_of_service_custom_labels['custom_field_1'] ?? __('lang_v1.service_custom_field_1');
                    $output['types_of_service_custom_fields'][$tos_custom_label_1] = $transaction->service_custom_field_1;
                }
                if (! empty($transaction->service_custom_field_2)) {
                    $tos_custom_label_2 = $types_of_service_custom_labels['custom_field_2'] ?? __('lang_v1.service_custom_field_2');
                    $output['types_of_service_custom_fields'][$tos_custom_label_2] = $transaction->service_custom_field_2;
                }
                if (! empty($transaction->service_custom_field_3)) {
                    $tos_custom_label_3 = $types_of_service_custom_labels['custom_field_3'] ?? __('lang_v1.service_custom_field_3');
                    $output['types_of_service_custom_fields'][$tos_custom_label_3] = $transaction->service_custom_field_3;
                }
                if (! empty($transaction->service_custom_field_4)) {
                    $tos_custom_label_4 = $types_of_service_custom_labels['custom_field_4'] ?? __('lang_v1.service_custom_field_4');
                    $output['types_of_service_custom_fields'][$tos_custom_label_4] = $transaction->service_custom_field_4;
                }

                if (! empty($transaction->service_custom_field_5)) {
                    $tos_custom_label_5 = $types_of_service_custom_labels['custom_field_5'] ?? __('lang_v1.service_custom_field_5');
                    $output['types_of_service_custom_fields'][$tos_custom_label_5] = $transaction->service_custom_field_5;
                }

                if (! empty($transaction->service_custom_field_6)) {
                    $tos_custom_label_6 = $types_of_service_custom_labels['custom_field_6'] ?? __('lang_v1.service_custom_field_6');
                    $output['types_of_service_custom_fields'][$tos_custom_label_6] = $transaction->service_custom_field_6;
                }
            }
        }

        if (! empty($il->module_info['service_staff']) && $this->isModuleEnabled('service_staff')) {
            //Waiter label & info
            $output['service_staff_label'] = null;
            $output['service_staff'] = null;
            if (isset($il->module_info['service_staff']['show_service_staff'])) {
                $output['service_staff_label'] = ! empty($il->module_info['service_staff']['service_staff_label']) ? $il->module_info['service_staff']['service_staff_label'] : '';
                if (! empty($transaction->res_waiter_id)) {
                    $waiter = \App\User::find($transaction->res_waiter_id);
                }

                //res_table_id
                $output['service_staff'] = ! empty($waiter->id) ? implode(' ', [$waiter->first_name, $waiter->last_name]) : '';
            }
        }

        //Repair module details
        if (! empty($il->module_info['repair']) && $transaction->sub_type == 'repair') {
            if (! empty($il->module_info['repair']['show_repair_status'])) {
                $output['repair_status_label'] = $il->module_info['repair']['repair_status_label'];
                $output['repair_status'] = '';
                if (! empty($transaction->repair_status_id)) {
                    $repair_status = \Modules\Repair\Entities\RepairStatus::find($transaction->repair_status_id);
                    $output['repair_status'] = $repair_status->name;
                }
            }

            if (! empty($il->module_info['repair']['show_repair_warranty'])) {
                $output['repair_warranty_label'] = $il->module_info['repair']['repair_warranty_label'];
                $output['repair_warranty'] = '';
                if (! empty($transaction->repair_warranty_id)) {
                    $repair_warranty = \App\Warranty::find($transaction->repair_warranty_id);
                    $output['repair_warranty'] = $repair_warranty->name;
                }
            }

            if (! empty($il->module_info['repair']['show_serial_no'])) {
                $output['serial_no_label'] = $il->module_info['repair']['serial_no_label'];
                $output['repair_serial_no'] = $transaction->repair_serial_no;
            }

            if (! empty($il->module_info['repair']['show_defects'])) {
                $output['defects_label'] = $il->module_info['repair']['defects_label'];
                $output['repair_defects'] = $transaction->repair_defects;
            }

            if (! empty($il->module_info['repair']['show_model'])) {
                $output['model_no_label'] = $il->module_info['repair']['model_no_label'];

                $output['repair_model_no'] = '';

                if (! empty($transaction->repair_model_id)) {
                    $device_model = \Modules\Repair\Entities\DeviceModel::find($transaction->repair_model_id);

                    if (! empty($device_model)) {
                        $output['repair_model_no'] = $device_model->name;
                    }
                }
            }

            if (! empty($il->module_info['repair']['show_repair_checklist'])) {
                $output['repair_checklist_label'] = $il->module_info['repair']['repair_checklist_label'];
                $output['checked_repair_checklist'] = $transaction->repair_checklist;

                $checklists = [];
                if (! empty($transaction->repair_model_id)) {
                    $model = \Modules\Repair\Entities\DeviceModel::find($transaction->repair_model_id);

                    if (! empty($model) && ! empty($model->repair_checklist)) {
                        $checklists = explode('|', $model->repair_checklist);
                    }
                }

                $output['repair_checklist'] = $checklists;
            }

            if (! empty($il->module_info['repair']['show_device'])) {
                $output['device_label'] = $il->module_info['repair']['device_label'];
                $device = \App\Category::find($transaction->repair_device_id);

                $output['repair_device'] = '';
                if (! empty($device)) {
                    $output['repair_device'] = $device->name;
                }
            }

            if (! empty($il->module_info['repair']['show_brand'])) {
                $output['brand_label'] = $il->module_info['repair']['brand_label'];
                $brand = \App\Brands::find($transaction->repair_brand_id);
                $output['repair_brand'] = '';
                if (! empty($brand)) {
                    $output['repair_brand'] = $brand->name;
                }
            }
        }

        //Custom fields
        $custom_labels = json_decode($business_details['custom_labels']);

        //shipping custom fields
        if (! empty($custom_labels->shipping->custom_field_1)) {
            $output['shipping_custom_field_1_label'] = $custom_labels->shipping->custom_field_1;
            $output['shipping_custom_field_1_value'] = $transaction['shipping_custom_field_1'];
        }

        if (! empty($custom_labels->shipping->custom_field_2)) {
            $output['shipping_custom_field_2_label'] = $custom_labels->shipping->custom_field_2;
            $output['shipping_custom_field_2_value'] = $transaction['shipping_custom_field_2'];
        }

        if (! empty($custom_labels->shipping->custom_field_3)) {
            $output['shipping_custom_field_3_label'] = $custom_labels->shipping->custom_field_3;
            $output['shipping_custom_field_3_value'] = $transaction['shipping_custom_field_3'];
        }

        if (! empty($custom_labels->shipping->custom_field_4)) {
            $output['shipping_custom_field_4_label'] = $custom_labels->shipping->custom_field_4;
            $output['shipping_custom_field_4_value'] = $transaction['shipping_custom_field_4'];
        }

        //Sell custom fields
        if (! empty($custom_labels->shipping->custom_field_5)) {
            $output['shipping_custom_field_5_label'] = $custom_labels->shipping->custom_field_5;
            $output['shipping_custom_field_5_value'] = $transaction['shipping_custom_field_5'];
        }


        $is_show_sell_custom_fields1 = ! empty($il->common_settings['sell_custom_fields1']) ? true : false;
        if (! empty($custom_labels->sell->custom_field_1) && $is_show_sell_custom_fields1) {
            $output['sell_custom_field_1_label'] = $custom_labels->sell->custom_field_1;
            $output['sell_custom_field_1_value'] = $transaction['custom_field_1'];
        }

        $is_show_sell_custom_fields2 = ! empty($il->common_settings['sell_custom_fields2']) ? true : false;
        if (! empty($custom_labels->sell->custom_field_2) && $is_show_sell_custom_fields2) {
            $output['sell_custom_field_2_label'] = $custom_labels->sell->custom_field_2;
            $output['sell_custom_field_2_value'] = $transaction['custom_field_2'];
        }

        $is_show_sell_custom_fields3 = ! empty($il->common_settings['sell_custom_fields3']) ? true : false;
        if (! empty($custom_labels->sell->custom_field_3) && $is_show_sell_custom_fields3) {
            $output['sell_custom_field_3_label'] = $custom_labels->sell->custom_field_3;
            $output['sell_custom_field_3_value'] = $transaction['custom_field_3'];
        }

        $is_show_sell_custom_fields4 = ! empty($il->common_settings['sell_custom_fields4']) ? true : false;
        if (! empty($custom_labels->sell->custom_field_4) && $is_show_sell_custom_fields4) {
            $output['sell_custom_field_4_label'] = $custom_labels->sell->custom_field_4;
            $output['sell_custom_field_4_value'] = $transaction['custom_field_4'];
        }



        // location custom fields
        if (in_array('custom_field1', $location_custom_field_settings) && ! empty($location_details->custom_field1) && ! empty($custom_labels->location->custom_field_1)) {
            $output['location_custom_field_1_label'] = $custom_labels->location->custom_field_1;
            $output['location_custom_field_1_value'] = $location_details->custom_field1;
        }

        if (in_array('custom_field2', $location_custom_field_settings) && ! empty($location_details->custom_field2) && ! empty($custom_labels->location->custom_field_2)) {
            $output['location_custom_field_2_label'] = $custom_labels->location->custom_field_2;
            $output['location_custom_field_2_value'] = $location_details->custom_field2;
        }

        if (in_array('custom_field3', $location_custom_field_settings) && ! empty($location_details->custom_field3) && ! empty($custom_labels->location->custom_field_3)) {
            $output['location_custom_field_3_label'] = $custom_labels->location->custom_field_3;
            $output['location_custom_field_3_value'] = $location_details->custom_field3;
        }

        if (in_array('custom_field4', $location_custom_field_settings) && ! empty($location_details->custom_field4) && ! empty($custom_labels->location->custom_field_4)) {
            $output['location_custom_field_4_label'] = $custom_labels->location->custom_field_4;
            $output['location_custom_field_4_value'] = $location_details->custom_field4;
        }

        //Used in pdfs
        if (! empty($transaction->sales_order_ids)) {
            $sale_orders = Transaction::where('type', 'sales_order')
                ->find($transaction->sales_order_ids);

            $output['sale_orders_invoice_no'] = implode(', ', $sale_orders->pluck('invoice_no')->toArray());
            $sale_orders_invoice_date = [];
            foreach ($sale_orders as $sale_order) {
                if (blank($il->date_time_format)) {
                    $sale_orders_invoice_date[] = $this->format_date($sale_order->transaction_date, true);
                } else {
                    $sale_orders_invoice_date[] = \Carbon::createFromFormat('Y-m-d H:i:s', $sale_order->transaction_date)->format($il->date_time_format);
                }
            }
            $output['sale_orders_invoice_date'] = implode(', ', $sale_orders_invoice_date);
        }

        if (! empty($transaction->prefer_payment_method)) {
            $payment_types = $this->payment_types(null, true, $transaction->business_id);
            $output['preferred_payment_method'] = $payment_types[$transaction->prefer_payment_method];
        }

        if (! empty($transaction->prefer_payment_account)) {
            $output['preferred_account_details'] = $transaction->preferredAccount->account_details;
        }

        //export custom fields
        $output['is_export'] = $transaction->is_export;
        $export_custom_fields_info = $transaction->export_custom_fields_info;
        if (! empty($transaction->is_export)) {
            $output['export_custom_fields_info']['export_custom_field_1'] = $export_custom_fields_info['export_custom_field_1'] ?? '';
            $output['export_custom_fields_info']['export_custom_field_2'] = $export_custom_fields_info['export_custom_field_2'] ?? '';
            $output['export_custom_fields_info']['export_custom_field_3'] = $export_custom_fields_info['export_custom_field_3'] ?? '';
            $output['export_custom_fields_info']['export_custom_field_4'] = $export_custom_fields_info['export_custom_field_4'] ?? '';
            $output['export_custom_fields_info']['export_custom_field_5'] = $export_custom_fields_info['export_custom_field_5'] ?? '';
            $output['export_custom_fields_info']['export_custom_field_6'] = $export_custom_fields_info['export_custom_field_6'] ?? '';
        }

        $output['design'] = $il->design;
        $output['table_tax_headings'] = ! empty($il->table_tax_headings) ? array_filter(json_decode($il->table_tax_headings), 'strlen') : null;

        return (object) $output;
    }

Step 7: Add Watermark Templates

Ultimate POS typically has multiple receipt templates (classic, modern, slim, etc.). You need to add the watermark code to each template you want to support watermarks.

Template Locations

Common template locations in Ultimate POS:

• resources/views/sale_pos/receipts/classic.blade.php
• resources/views/sale_pos/receipts/detailed.blade.php
• resources/views/sale_pos/receipts/columnize-taxes.blade.php
• resources/views/sale_pos/receipts/elegant.blade.php
• Any custom templates you've created

Universal Watermark Code

Add this watermark code to each template. The placement depends on the template structure:

For table-based templates (like elegant):
Add this code at the very beginning of your template

<!-- Watermark Implementation -->
@if(!empty($receipt_details->watermark_logo) && !empty($receipt_details->show_watermark))
<style>
	.watermark {
		position: fixed;
		top: 50%;
		left: 50%;
		transform: translate(-50%, -50%);

		opacity: {
				{
				$receipt_details->watermark_opacity ?? '0.15'
			}
		}

		;
		/* Slightly more visible */
		z-index: -1;
		pointer-events: none;
	}

	.transparent-content {
		position: relative;
		background-color: rgba(255, 255, 255, 0.1) !important;
		/* Semi-transparent white */
	}

	.transparent-content td,
	.transparent-content th {
		background-color: transparent !important;
	}
</style>
<div style="position: fixed;
            top: 50%;
            left: 50%;
            transform: translate(-50%, -50%);
            opacity: {{ $receipt_details->watermark_opacity ?? '0.1' }};
            z-index: -1;
            pointer-events: none;">
	<img src="{{ asset('uploads/invoice_logos/' . $receipt_details->watermark_logo) }}" style="width: {{ $receipt_details->watermark_width ?? '300' }}px;
                height: {{ $receipt_details->watermark_height ?? '300' }}px;
                object-fit: contain;">
</div>
@endif

then update <table> tag

<table class="transparent-content" style="width:100%; color: #000000 !important;">

For div-based templates (like classic):

<!-- Add this wrapper div at the very beginning of the template -->
<div style="position: relative;">

	<!-- Watermark Logo -->
	@if(!empty($receipt_details->watermark_logo) && !empty($receipt_details->show_watermark))
	@php
	$position_styles = match($receipt_details->watermark_position ?? 'center') {
	'center' => 'top: 300px; left: 50%; transform: translateX(-50%);',
	'top-left' => 'top: 50px; left: 50px;',
	'top-right' => 'top: 50px; right: 50px;',
	'bottom-left' => 'bottom: 50px; left: 50px;',
	'bottom-right' => 'bottom: 50px; right: 50px;',
	default => 'top: 300px; left: 50%; transform: translateX(-50%);'
	};
	@endphp
	<div style="
			position: absolute;
			{{ $position_styles }}
			opacity: {{ $receipt_details->watermark_opacity ?? '0.1' }};
			z-index: 1;
			pointer-events: none;
		">
		<img src="{{asset('uploads/invoice_logos/' . $receipt_details->watermark_logo)}}" alt="Watermark" style="
				 	width: {{$receipt_details->watermark_width ?? '300'}}px;
				 	height: {{$receipt_details->watermark_height ?? '300'}}px;
				 	object-fit: contain;
				 ">
	</div>
	@endif

	<!-- All existing content with higher z-index -->
	<div style="position: relative; z-index: 2;">

		<!-- business information here -->
		<div class="row" style="color: #000000 !important; background: rgba(255,255,255,0.9);">
			<!-- Logo -->
			@if(empty($receipt_details->letter_head))
			@if(!empty($receipt_details->logo))
			<img style="max-height: 120px; width: auto;" src="{{$receipt_details->logo}}"
				class="img img-responsive center-block">
			@endif

			<!-- Header text -->
			@if(!empty($receipt_details->header_text))
			<div class="col-xs-12">
				{!! $receipt_details->header_text !!}
			</div>
			@endif

			<!-- business information here -->
			<div class="col-xs-12 text-center">
				<h2 class="text-center">
					<!-- Shop & Location Name  -->
					@if(!empty($receipt_details->display_name))
					{{$receipt_details->display_name}}
					@endif
				</h2>

				<!-- Address -->
				<p>
					@if(!empty($receipt_details->address))
					<small class="text-center">
						{!! $receipt_details->address !!}
					</small>
					@endif
					@if(!empty($receipt_details->contact))
					<br />{!! $receipt_details->contact !!}
					@endif
					@if(!empty($receipt_details->contact) && !empty($receipt_details->website))
					,
					@endif
					@if(!empty($receipt_details->website))
					{{ $receipt_details->website }}
					@endif
					@if(!empty($receipt_details->location_custom_fields))
					<br>{{ $receipt_details->location_custom_fields }}
					@endif
				</p>
				<p>
					@if(!empty($receipt_details->sub_heading_line1))
					{{ $receipt_details->sub_heading_line1 }}
					@endif
					@if(!empty($receipt_details->sub_heading_line2))
					<br>{{ $receipt_details->sub_heading_line2 }}
					@endif
					@if(!empty($receipt_details->sub_heading_line3))
					<br>{{ $receipt_details->sub_heading_line3 }}
					@endif
					@if(!empty($receipt_details->sub_heading_line4))
					<br>{{ $receipt_details->sub_heading_line4 }}
					@endif
					@if(!empty($receipt_details->sub_heading_line5))
					<br>{{ $receipt_details->sub_heading_line5 }}
					@endif
				</p>
				<p>
					@if(!empty($receipt_details->tax_info1))
					<b>{{ $receipt_details->tax_label1 }}</b> {{ $receipt_details->tax_info1 }}
					@endif

					@if(!empty($receipt_details->tax_info2))
					<b>{{ $receipt_details->tax_label2 }}</b> {{ $receipt_details->tax_info2 }}
					@endif
				</p>
				@endif


				<!-- Title of receipt -->
				@if(!empty($receipt_details->invoice_heading))
				<h3 class="text-center">
					{!! $receipt_details->invoice_heading !!}
				</h3>
				@endif
			</div>
			@if(!empty($receipt_details->letter_head))
			<div class="col-xs-12 text-center">
				<img style="width: 100%;margin-bottom: 10px;" src="{{$receipt_details->letter_head}}">
			</div>
			@endif
			<div class="col-xs-12 text-center">
				<!-- Invoice  number, Date  -->
				<p style="width: 100% !important" class="word-wrap">
					<span class="pull-left text-left word-wrap">
						@if(!empty($receipt_details->invoice_no_prefix))
						<b>{!! $receipt_details->invoice_no_prefix !!}</b>
						@endif
						{{$receipt_details->invoice_no}}

						@if(!empty($receipt_details->types_of_service))
						<br />
						<span class="pull-left text-left">
							<strong>{!! $receipt_details->types_of_service_label !!}:</strong>
							{{$receipt_details->types_of_service}}
							<!-- Waiter info -->
							@if(!empty($receipt_details->types_of_service_custom_fields))
							@foreach($receipt_details->types_of_service_custom_fields as $key => $value)
							<br><strong>{{$key}}: </strong> {{$value}}
							@endforeach
							@endif
						</span>
						@endif

						<!-- Table information-->
						@if(!empty($receipt_details->table_label) || !empty($receipt_details->table))
						<br />
						<span class="pull-left text-left">
							@if(!empty($receipt_details->table_label))
							<b>{!! $receipt_details->table_label !!}</b>
							@endif
							{{$receipt_details->table}}

							<!-- Waiter info -->
						</span>
						@endif

						<!-- customer info -->
						@if(!empty($receipt_details->customer_info))
						<br />
						<b>{{ $receipt_details->customer_label }}</b> <br> {!! $receipt_details->customer_info !!} <br>
						@endif
						@if(!empty($receipt_details->client_id_label))
						<br />
						<b>{{ $receipt_details->client_id_label }}</b> {{ $receipt_details->client_id }}
						@endif
						@if(!empty($receipt_details->customer_tax_label))
						<br />
						<b>{{ $receipt_details->customer_tax_label }}</b> {{ $receipt_details->customer_tax_number }}
						@endif
						@if(!empty($receipt_details->customer_custom_fields))
						<br />{!! $receipt_details->customer_custom_fields !!}
						@endif
						@if(!empty($receipt_details->sales_person_label))
						<br />
						<b>{{ $receipt_details->sales_person_label }}</b> {{ $receipt_details->sales_person }}
						@endif
						@if(!empty($receipt_details->commission_agent_label))
						<br />
						<strong>{{ $receipt_details->commission_agent_label }}</strong> {{
						$receipt_details->commission_agent }}
						@endif
						@if(!empty($receipt_details->customer_rp_label))
						<br />
						<strong>{{ $receipt_details->customer_rp_label }}</strong> {{
						$receipt_details->customer_total_rp }}
						@endif
					</span>

					<span class="pull-right text-left">
						<b>{{$receipt_details->date_label}}</b> {{$receipt_details->invoice_date}}

						@if(!empty($receipt_details->due_date_label))
						<br><b>{{$receipt_details->due_date_label}}</b> {{$receipt_details->due_date ?? ''}}
						@endif

						@if(!empty($receipt_details->brand_label) || !empty($receipt_details->repair_brand))
						<br>
						@if(!empty($receipt_details->brand_label))
						<b>{!! $receipt_details->brand_label !!}</b>
						@endif
						{{$receipt_details->repair_brand}}
						@endif


						@if(!empty($receipt_details->device_label) || !empty($receipt_details->repair_device))
						<br>
						@if(!empty($receipt_details->device_label))
						<b>{!! $receipt_details->device_label !!}</b>
						@endif
						{{$receipt_details->repair_device}}
						@endif

						@if(!empty($receipt_details->model_no_label) || !empty($receipt_details->repair_model_no))
						<br>
						@if(!empty($receipt_details->model_no_label))
						<b>{!! $receipt_details->model_no_label !!}</b>
						@endif
						{{$receipt_details->repair_model_no}}
						@endif

						@if(!empty($receipt_details->serial_no_label) || !empty($receipt_details->repair_serial_no))
						<br>
						@if(!empty($receipt_details->serial_no_label))
						<b>{!! $receipt_details->serial_no_label !!}</b>
						@endif
						{{$receipt_details->repair_serial_no}}<br>
						@endif
						@if(!empty($receipt_details->repair_status_label) || !empty($receipt_details->repair_status))
						@if(!empty($receipt_details->repair_status_label))
						<b>{!! $receipt_details->repair_status_label !!}</b>
						@endif
						{{$receipt_details->repair_status}}<br>
						@endif

						@if(!empty($receipt_details->repair_warranty_label) ||
						!empty($receipt_details->repair_warranty))
						@if(!empty($receipt_details->repair_warranty_label))
						<b>{!! $receipt_details->repair_warranty_label !!}</b>
						@endif
						{{$receipt_details->repair_warranty}}
						<br>
						@endif

						<!-- Waiter info -->
						@if(!empty($receipt_details->service_staff_label) || !empty($receipt_details->service_staff))
						<br />
						@if(!empty($receipt_details->service_staff_label))
						<b>{!! $receipt_details->service_staff_label !!}</b>
						@endif
						{{$receipt_details->service_staff}}
						@endif
						@if(!empty($receipt_details->shipping_custom_field_1_label))
						<br><strong>{!!$receipt_details->shipping_custom_field_1_label!!} :</strong>
						{!!$receipt_details->shipping_custom_field_1_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->shipping_custom_field_2_label))
						<br><strong>{!!$receipt_details->shipping_custom_field_2_label!!}:</strong>
						{!!$receipt_details->shipping_custom_field_2_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->shipping_custom_field_3_label))
						<br><strong>{!!$receipt_details->shipping_custom_field_3_label!!}:</strong>
						{!!$receipt_details->shipping_custom_field_3_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->shipping_custom_field_4_label))
						<br><strong>{!!$receipt_details->shipping_custom_field_4_label!!}:</strong>
						{!!$receipt_details->shipping_custom_field_4_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->shipping_custom_field_5_label))
						<br><strong>{!!$receipt_details->shipping_custom_field_2_label!!}:</strong>
						{!!$receipt_details->shipping_custom_field_5_value ?? ''!!}
						@endif
						{{-- sale order --}}
						@if(!empty($receipt_details->sale_orders_invoice_no))
						<br>
						<strong>@lang('restaurant.order_no'):</strong> {!!$receipt_details->sale_orders_invoice_no ??
						''!!}
						@endif

						@if(!empty($receipt_details->sale_orders_invoice_date))
						<br>
						<strong>@lang('lang_v1.order_dates'):</strong> {!!$receipt_details->sale_orders_invoice_date ??
						''!!}
						@endif

						@if(!empty($receipt_details->sell_custom_field_1_value))
						<br>
						<strong>{{ $receipt_details->sell_custom_field_1_label }}:</strong>
						{!!$receipt_details->sell_custom_field_1_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->sell_custom_field_2_value))
						<br>
						<strong>{{ $receipt_details->sell_custom_field_2_label }}:</strong>
						{!!$receipt_details->sell_custom_field_2_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->sell_custom_field_3_value))
						<br>
						<strong>{{ $receipt_details->sell_custom_field_3_label }}:</strong>
						{!!$receipt_details->sell_custom_field_3_value ?? ''!!}
						@endif

						@if(!empty($receipt_details->sell_custom_field_4_value))
						<br>
						<strong>{{ $receipt_details->sell_custom_field_4_label }}:</strong>
						{!!$receipt_details->sell_custom_field_4_value ?? ''!!}
						@endif

					</span>
				</p>
			</div>
		</div>

		<div class="row" style="color: #000000 !important; background: rgba(255,255,255,0.9);">
			@includeIf('sale_pos.receipts.partial.common_repair_invoice')
		</div>

		<div class="row" style="color: #000000 !important; background: rgba(255,255,255,0.9);">
			<div class="col-xs-12">
				<br />
				@php
				$p_width = 45;
				@endphp
				@if(!empty($receipt_details->item_discount_label))
				@php
				$p_width -= 10;
				@endphp
				@endif
				@if(!empty($receipt_details->discounted_unit_price_label))
				@php
				$p_width -= 10;
				@endphp
				@endif
				<table class="table table-responsive table-slim" style="background: transparent;">
					<thead>
						<tr>
							<th width="{{$p_width}}%">{{$receipt_details->table_product_label}}</th>
							<th class="text-right" width="15%">{{$receipt_details->table_qty_label}}</th>
							<th class="text-right" width="15%">{{$receipt_details->table_unit_price_label}}</th>
							@if(!empty($receipt_details->discounted_unit_price_label))
							<th class="text-right" width="10%">{{$receipt_details->discounted_unit_price_label}}</th>
							@endif
							@if(!empty($receipt_details->item_discount_label))
							<th class="text-right" width="10%">{{$receipt_details->item_discount_label}}</th>
							@endif
							<th class="text-right" width="15%">{{$receipt_details->table_subtotal_label}}</th>
						</tr>
					</thead>
					<tbody>
						@forelse($receipt_details->lines as $line)
						<tr style="background: rgba(255,255,255,0.8);">
							<td>
								@if(!empty($line['image']))
								<img src="{{$line['image']}}" alt="Image" width="50"
									style="float: left; margin-right: 8px;">
								@endif
								{{$line['name']}} {{$line['product_variation']}} {{$line['variation']}}
								@if(!empty($line['sub_sku'])), {{$line['sub_sku']}} @endif @if(!empty($line['brand'])),
								{{$line['brand']}} @endif @if(!empty($line['cat_code'])), {{$line['cat_code']}}@endif
								@if(!empty($line['product_custom_fields'])), {{$line['product_custom_fields']}} @endif
								@if(!empty($line['product_description']))
								<small>
									{!!$line['product_description']!!}
								</small>
								@endif
								@if(!empty($line['sell_line_note']))
								<br>
								<small>
									{!!$line['sell_line_note']!!}
								</small>
								@endif
								@if(!empty($line['lot_number']))<br> {{$line['lot_number_label']}}:
								{{$line['lot_number']}} @endif
								@if(!empty($line['product_expiry'])), {{$line['product_expiry_label']}}:
								{{$line['product_expiry']}} @endif

								@if(!empty($line['warranty_name'])) <br><small>{{$line['warranty_name']}} </small>@endif
								@if(!empty($line['warranty_exp_date'])) <small>-
									{{@format_date($line['warranty_exp_date'])}} </small>@endif
								@if(!empty($line['warranty_description'])) <small> {{$line['warranty_description'] ??
									''}}</small>@endif

								@if($receipt_details->show_base_unit_details && $line['quantity'] &&
								$line['base_unit_multiplier'] !== 1)
								<br><small>
									1 {{$line['units']}} = {{$line['base_unit_multiplier']}} {{$line['base_unit_name']}}
									<br>
									{{$line['base_unit_price']}} x {{$line['orig_quantity']}} = {{$line['line_total']}}
								</small>
								@endif
							</td>
							<td class="text-right">
								{{$line['quantity']}} {{$line['units']}}

								@if($receipt_details->show_base_unit_details && $line['quantity'] &&
								$line['base_unit_multiplier'] !== 1)
								<br><small>
									{{$line['quantity']}} x {{$line['base_unit_multiplier']}} =
									{{$line['orig_quantity']}} {{$line['base_unit_name']}}
								</small>
								@endif
							</td>
							<td class="text-right">{{$line['unit_price_before_discount']}}</td>
							@if(!empty($receipt_details->discounted_unit_price_label))
							<td class="text-right">
								{{$line['unit_price_inc_tax']}}
							</td>
							@endif
							@if(!empty($receipt_details->item_discount_label))
							<td class="text-right">
								{{$line['total_line_discount'] ?? '0.00'}}

								@if(!empty($line['line_discount_percent']))
								({{$line['line_discount_percent']}}%)
								@endif
							</td>
							@endif
							<td class="text-right">{{$line['line_total']}}</td>
						</tr>
						@if(!empty($line['modifiers']))
						@foreach($line['modifiers'] as $modifier)
						<tr style="background: rgba(255,255,255,0.8);">
							<td>
								{{$modifier['name']}} {{$modifier['variation']}}
								@if(!empty($modifier['sub_sku'])), {{$modifier['sub_sku']}} @endif
								@if(!empty($modifier['cat_code'])), {{$modifier['cat_code']}}@endif
								@if(!empty($modifier['sell_line_note']))({!!$modifier['sell_line_note']!!}) @endif
							</td>
							<td class="text-right">{{$modifier['quantity']}} {{$modifier['units']}} </td>
							<td class="text-right">{{$modifier['unit_price_inc_tax']}}</td>
							@if(!empty($receipt_details->discounted_unit_price_label))
							<td class="text-right">{{$modifier['unit_price_exc_tax']}}</td>
							@endif
							@if(!empty($receipt_details->item_discount_label))
							<td class="text-right">0.00</td>
							@endif
							<td class="text-right">{{$modifier['line_total']}}</td>
						</tr>
						@endforeach
						@endif
						@empty
						<tr style="background: rgba(255,255,255,0.8);">
							<td colspan="4">&nbsp;</td>
							@if(!empty($receipt_details->discounted_unit_price_label))
							<td></td>
							@endif
							@if(!empty($receipt_details->item_discount_label))
							<td></td>
							@endif
						</tr>
						@endforelse
					</tbody>
				</table>
			</div>
		</div>

		<div class="row" style="color: #000000 !important; background: rgba(255,255,255,0.9);">
			<div class="col-md-12">
				<hr />
			</div>
			<div class="col-xs-6">

				<table class="table table-slim" style="background: transparent;">

					@if(!empty($receipt_details->payments))
					@foreach($receipt_details->payments as $payment)
					<tr>
						<td>{{$payment['method']}}</td>
						<td class="text-right">{{$payment['amount']}}</td>
						<td class="text-right">{{$payment['date']}}</td>
					</tr>
					@endforeach
					@endif

					<!-- Total Paid-->
					@if(!empty($receipt_details->total_paid))
					<tr>
						<th>
							{!! $receipt_details->total_paid_label !!}
						</th>
						<td class="text-right">
							{{$receipt_details->total_paid}}
						</td>
					</tr>
					@endif

					<!-- Total Due-->
					@if(!empty($receipt_details->total_due) && !empty($receipt_details->total_due_label))
					<tr>
						<th>
							{!! $receipt_details->total_due_label !!}
						</th>
						<td class="text-right">
							{{$receipt_details->total_due}}
						</td>
					</tr>
					@endif

					@if(!empty($receipt_details->all_due))
					<tr>
						<th>
							{!! $receipt_details->all_bal_label !!}
						</th>
						<td class="text-right">
							{{$receipt_details->all_due}}
						</td>
					</tr>
					@endif
				</table>
			</div>

			<div class="col-xs-6">
				<div class="table-responsive">
					<table class="table table-slim" style="background: transparent;">
						<tbody>
							@if(!empty($receipt_details->total_quantity_label))
							<tr>
								<th style="width:70%">
									{!! $receipt_details->total_quantity_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->total_quantity}}
								</td>
							</tr>
							@endif

							@if(!empty($receipt_details->total_items_label))
							<tr>
								<th style="width:70%">
									{!! $receipt_details->total_items_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->total_items}}
								</td>
							</tr>
							@endif
							<tr>
								<th style="width:70%">
									{!! $receipt_details->subtotal_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->subtotal}}
								</td>
							</tr>
							@if(!empty($receipt_details->total_exempt_uf))
							<tr>
								<th style="width:70%">
									@lang('lang_v1.exempt')
								</th>
								<td class="text-right">
									{{$receipt_details->total_exempt}}
								</td>
							</tr>
							@endif
							<!-- Shipping Charges -->
							@if(!empty($receipt_details->shipping_charges))
							<tr>
								<th style="width:70%">
									{!! $receipt_details->shipping_charges_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->shipping_charges}}
								</td>
							</tr>
							@endif

							@if(!empty($receipt_details->packing_charge))
							<tr>
								<th style="width:70%">
									{!! $receipt_details->packing_charge_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->packing_charge}}
								</td>
							</tr>
							@endif

							<!-- Discount -->
							@if( !empty($receipt_details->discount) )
							<tr>
								<th>
									{!! $receipt_details->discount_label !!}
								</th>

								<td class="text-right">
									(-) {{$receipt_details->discount}}
								</td>
							</tr>
							@endif

							@if( !empty($receipt_details->total_line_discount) )
							<tr>
								<th>
									{!! $receipt_details->line_discount_label !!}
								</th>

								<td class="text-right">
									(-) {{$receipt_details->total_line_discount}}
								</td>
							</tr>
							@endif

							@if( !empty($receipt_details->additional_expenses) )
							@foreach($receipt_details->additional_expenses as $key => $val)
							<tr>
								<td>
									{{$key}}:
								</td>

								<td class="text-right">
									(+) {{$val}}
								</td>
							</tr>
							@endforeach
							@endif

							@if( !empty($receipt_details->reward_point_label) )
							<tr>
								<th>
									{!! $receipt_details->reward_point_label !!}
								</th>

								<td class="text-right">
									(-) {{$receipt_details->reward_point_amount}}
								</td>
							</tr>
							@endif

							<!-- Tax -->
							@if( !empty($receipt_details->tax) )
							<tr>
								<th>
									{!! $receipt_details->tax_label !!}
								</th>
								<td class="text-right">
									(+) {{$receipt_details->tax}}
								</td>
							</tr>
							@endif

							@if( $receipt_details->round_off_amount > 0)
							<tr>
								<th>
									{!! $receipt_details->round_off_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->round_off}}
								</td>
							</tr>
							@endif

							<!-- Total -->
							<tr>
								<th>
									{!! $receipt_details->total_label !!}
								</th>
								<td class="text-right">
									{{$receipt_details->total}}
									@if(!empty($receipt_details->total_in_words))
									<br>
									<small>({{$receipt_details->total_in_words}})</small>
									@endif
								</td>
							</tr>
						</tbody>
					</table>
				</div>
			</div>

			<div class="border-bottom col-md-12">
				@if(empty($receipt_details->hide_price) && !empty($receipt_details->tax_summary_label) )
				<!-- tax -->
				@if(!empty($receipt_details->taxes))
				<table class="table table-slim table-bordered" style="background: rgba(255,255,255,0.9);">
					<tr>
						<th colspan="2" class="text-center">{{$receipt_details->tax_summary_label}}</th>
					</tr>
					@foreach($receipt_details->taxes as $key => $val)
					<tr>
						<td class="text-center"><b>{{$key}}</b></td>
						<td class="text-center">{{$val}}</td>
					</tr>
					@endforeach
				</table>
				@endif
				@endif
			</div>

			@if(!empty($receipt_details->additional_notes))
			<div class="col-xs-12">
				<p>{!! nl2br($receipt_details->additional_notes) !!}</p>
			</div>
			@endif

		</div>
		<div class="row" style="color: #000000 !important; background: rgba(255,255,255,0.9);">
			@if(!empty($receipt_details->footer_text))
			<div
				class="@if($receipt_details->show_barcode || $receipt_details->show_qr_code) col-xs-8 @else col-xs-12 @endif">
				{!! $receipt_details->footer_text !!}
			</div>
			@endif
			@if($receipt_details->show_barcode || $receipt_details->show_qr_code)
			<div class="@if(!empty($receipt_details->footer_text)) col-xs-4 @else col-xs-12 @endif text-center">
				@if($receipt_details->show_barcode)
				{{-- Barcode --}}
				<img class="center-block"
				@endif

				@if($receipt_details->show_qr_code && !empty($receipt_details->qr_code_text))
				<img class="center-block mt-5"
				@endif
			</div>
			@endif
		</div>

	</div> <!-- End of content wrapper -->

</div> <!-- End of watermark container -->

Step 8: Testing

Test the Implementation

1. Access Invoice Settings

   • Go to your invoice layout settings
   • You should see the new watermark section

2. Upload Watermark

   • Upload a watermark image
   • Set desired size, opacity, and position
   • Enable "Show Watermark" checkbox
   • Save the layout

3. Generate Invoice

   • Create a test invoice
   • Verify watermark appears with correct settings
   • Check that text remains readable

4. Test Different Settings

   • Try different opacity levels (5% - 30%)
   • Test different positions (center, corners)
   • Adjust size settings
   • Verify changes reflect on invoices

Step 9: Troubleshooting

Common Issues and Solutions

Watermark Not Showing

• Check if show_watermark is enabled
• Verify watermark file exists in uploads/invoice_logos/
• Ensure correct file permissions

404 Error for Watermark Image

• Verify image path in template: uploads/invoice_logos/filename
• Check file upload was successful
• Confirm file exists on server

Watermark Hidden Behind Table

• Ensure proper z-index values are set
• Add transparency to table rows
• Check CSS positioning

Form Not Saving Settings

• Verify all fields are in controller's $request->only() array
• Check validation rules include watermark fields
• Ensure database columns exist

File Permissions

Ensure proper permissions for upload directory:

chmod 755 public/uploads/invoice_logos/
chown www-data:www-data public/uploads/invoice_logos/

Step 10: Customization Options

Advanced Customizations

Add More Position Options

You can extend the position dropdown with additional options like:

• Top center
• Bottom center
• Custom coordinates

Dynamic Opacity

Implement slider control for opacity instead of dropdown.

Multiple Watermarks

Extend to support multiple watermarks per invoice.

Conditional Watermarks

Add logic to show different watermarks based on customer type, invoice amount, etc.

File Structure

After implementation, your key files should include:

├── app/
│   ├── InvoiceLayout.php (updated)
│   └── Http/Controllers/InvoiceLayoutController.php (updated)
├── database/migrations/
│   └── add_watermark_fields_to_invoice_layouts.php (new)
├── resources/
│   ├── lang/en/lang_v1.php (updated)
│   └── views/
│       ├── invoice_layouts/create.blade.php (updated)
│       ├── invoice_layouts/edit.blade.php (updated)
│       └── receipts/invoice_template.blade.php (updated)
└── public/uploads/invoice_logos/ (watermark storage)

Security Considerations

• Validate uploaded images (file type, size)
• Implement proper file naming to prevent conflicts
• Set appropriate file permissions
• Consider file size limits for performance

Performance Notes

• Watermark images should be optimized for web
• Consider caching for frequently accessed watermarks
• Monitor storage usage for uploaded watermarks
• Implement cleanup for unused watermark files

Conclusion

The watermark feature is now fully implemented in your Ultimate POS system. Users can upload custom watermarks, adjust their appearance, and position them on invoices while maintaining text readability.

For additional customizations or troubleshooting, refer to the Laravel documentation and Ultimate POS codebase structure.

💬 Discussion & Questions

Please sign in to join the discussion.

Loading comments...
